LK CubicSecure - An intelligent water safety system
Design
LK CubicSecure is a water safety system that pro-
tects against leakage by continuously measuring
water consumption, water pressure and tempera-
ture. The unit emits alarms for both micro-leaks
and larger leaks. When the water safety system
detects a leak, it automatically shuts off the water
flow. The water circuit breaker can be installed in
villas, terraced houses and apartments (1).
System description
LK CubicSecure is a small unit that is easy to
install in confined spaces. The unit is easily in-
stalled on incoming water pipes for a house or
apartment. The water safety system is equipped
with a switch for manual shut-off in the event of
power failure or emergency.
NOTE!
Two water safety systems can be paired in
order to avoid scalding in apartments. Pairing
provides a synchronised automatic shut-off
between the hot and cold water pipes.
With the MyLK app and Wifi connectivity, you can
remotely control the unit to shut the water off or
on, acknowledge alarms and monitor your water
consumption, for example.
MyLK app.
QR code to MyLK app.
Installation instructions | LK CubicSecure
LK CubicSecure.
TABLE OF CONTENTS
Installation
1
1
2
2
3
3
4
4
5
6
6
7
7
7
7
7
EN.40.C.12.2023-01-31
1 (7)
Advertisement
Table of Contents
Related Manuals for LK CubicSecure
Summary of Contents for LK CubicSecure
- Page 1 The water circuit breaker can be installed in villas, terraced houses and apartments (1). System description LK CubicSecure is a small unit that is easy to install in confined spaces. The unit is easily in- stalled on incoming water pipes for a house or apartment.
- Page 2 G20 EuroCone external thread which is to be installed with an LK PressPex press connection coupling or LK Pushfit AX connection coupling. When using a flat gasket, LK Plain Adapter is supplied (RKS-187 06 78) with the product. The water safety system and the incoming water pipe.
- Page 3 2. Check that the STATUS LED is WHITE. White light indicates that the device is oper- ating normally when CubicSecure is installed on a water-filled pipe. If not installed on a pipe filled with water, the unit will not glow WHITE.
- Page 4 Manual pairing Power failure/Restart 1. Install and start the units. One for hot water After a power failure, the device returns to the and one for cold water. same mode it was in before the power failure. 2. Hold down the CONNECT button for five seconds on the unit installed for cold water.
- Page 5 Start-up and function check WATER ON/ Meaning OFF LED Check that the ball valve is working The water pressure is very 1. Press the WATER ON/OFF button. low or there is no water in the pipe. Check that the water The LED stops lighting when the ball valve system is working properly.
- Page 6 Various data such as temperature, volume, water pressure, valve position and no leakage detected are displayed for each unit. When LK CubicSe- cure is in operation, it performs automatic leak- age tests and exercise the valve. If a fault occurs...
- Page 7 If LK is responsi- Nominal flow rate (Q3) 4,000 l/h ble for the fault in the product, LK has the right to Start, flow 6 l/h replace the product with either a new or repaired Micro-leakage detected >0.5 bar pressure loss.
