- Page 1 DAEA520 Earth auger USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. PARTS LOCATION ........................... 2 2. SPECIFICATION ............................3 3. SYMBOLS ON THE MACHINE ........................ 3 4. WARNING LABELS ON THE MACHINE ....................3 5. FOR SAFE OPERATION ........................... 5 6. FUEL ................................. 7 7. OPERATION ............................. 8 8. MAINTENANCE ............................. 11 9. -
Page 3: Parts Location
1. PARTS LOCATION 1. Right Grip 2. Left Grip 3. Fuel Tank 4. Frame 5. Gear transmission 6. Driller (optional) 7. Throttle lever 8. ON/OFF Switch 9. Recoil Stater 10. Primer Bulb... -
Page 4: Specification
2. SPECIFICATION Engine type: TT1E44F(air-cooled, 2-stroke) Engine displacement: 52 cc Maximum engine power: 3.0 hp / 2.2kw Engine Max speed: 10000 rpm Engine idling speed: 3000±300 rpm Fuel Mixture Petrol: Gasoline 25 Oil: 1 Volume of fuel tank: 1.2 L Starter: Recoil Carburetor: Diaphragm type Weight (without driller and petrol): 9.0 kg... - Page 5 Read the instruction manual completely and carefully before using the power tool. Don’t smoke or allow flames on the machine Wear hearing protection! Danger of hot components Wear safety glasses! With this symbol the manufacturer confirms that this tool is in accordance with applica ble European directives.
-
Page 6: For Safe Operation
you don't observe the proper usage written in the manual. 5. FOR SAFE OPERATION 1. Read this manual carefully until you completely understand and follow all safety and operating instructions. 2. Keep this manual handy so that you may refer to it later whenever any questions arise. Also note, if you have any questions which cannot be answered herein, contact the dealer from whom you purchased the product. - Page 7 (See USING THE PRODUCT), Repetitive Stress Injury (RSI) could occur. If you feel discomfort, redness and swelling of your fingers or any other part of your body, see a doctor before getting worse. 2. To avoid noise complaints, in general, operate product between 8a.m. and 5p.m. on weekdays and 9a.m.
-
Page 8: Fuel
1. Guard against hazardous situations at all times. Warn adults to keep pets and children away from the area. Be careful if you are approached. Injury may result from flying debris. 2. If someone calls out or otherwise interrupts you while working, always be sure to turn off the engine before turning around. -
Page 9: Operation
2. Put some of the petrol into the clean, approved fuel container supplied. 3. Pour in the oil and agitate well. 4. Be careful that, if the agitation is insufficient, there is an increased danger of early piston seizing due to abnormally lean mixture. FUELING THE UNIT 1. - Page 10 4. Move the choke lever to the OFF position. 5. Set the ignition switch to the “ON” position. 6. Place the unit on a flat, firm place. While holding the unit firmly, pull out the starter rope quickly until engine fires. •...
- Page 11 8. Allow the engine to warm up for several minutes before starting operation. NOTE 1. When restarting the engine immediately after stopping it, leave the choke at ON position. 2. Overchoking can make the engine hard to start due to excess fuel. When the engine failed to start after several attempts, open the choke and repeat pulling the rope, or remove the spark plug and dry it.
-
Page 12: Maintenance
DRILLING • Keep a firm grip of the auger at all times on a wide stance and by holding the handle with both hands. • A reacting motion may occur on the auger when spinning driller has hit on stones or tree roots under the ground. - Page 13 WARNING • Always be sure to stop the engine before inspecting the brush cutter for problems or performing maintenance. • Never alter the auger or take the engine apart. AIR FILTER • The air filter, if clogged, will reduce the engine performance. Monthly check and clean the filter element in warm, soapy water as required.
-
Page 14: Storage
• To install the spark plug, first turn the plug until it is finger tight, then tighten it a quarter turn more with a socket wrench. TIGHTENING TORQUE: 9.8~11.8 N.m MUFFLER WARNING • Inspect periodically, the muffler for loose fasteners, any damage or corrosion. If any sign of exhaust leakage is found, do not use the brush cutter and have it repaired immediately. -
Page 15: Troubleshooting Guide
10. TROUBLESHOOTING GUIDE Case 1. Starting failure CHECK PROBABLE CAUSES ACTION fuel tank ► incorrect fuel ► drain it and use correct fuel fuel filter ► fuel filter is clogged ► clean carburetor adjustment screw out of normal range adjust to normal range ►... -
Page 16: Warranty
WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 6 months for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed. - Page 17 Manufactured under license of Daewoo International Corporation, Korea...
