- Page 1 DASG15 Garden socket outlet USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
- Page 2 INDEX 1. INTENDED USE ............................2 2. SAFETY INSTRUCTIONS ........................2 3. COMMISSIONING AND OPERATION ..................... 3 4. TECHNICAL SPECIFICATIONS ....................... 3 5. PRODUCT DESCRIPTION ........................4 6. EXPLODED VIEW AND SPARE PART LIST ..................... 5 WARRANTY ..............................6...
- Page 3 1. INTENDED USE The garden socket is designed for outdoor installation. The garden socket can either be placed securely in the ground or used as a mobile garden extension (no permanent installation permitted). Any other use than specified in these instructions for use, is not permitted as this will damage the product.
- Page 4 Scope of delivery Immediately after unpacking, check that the scope of delivery is complete and that the product is in perfect condition. 1 x ground spike 1 x housing including 4 sockets and about 1.5 m, 5 m or 10 m power cord 1 x instruction manual 3.
- Page 5 5. PRODUCT DESCRIPTION 1. Plug (JL-3F) 2. Cable (H07RN-F 3G1.5 mm2) 3. Socket (XS-XBD4)
- Page 6 6. EXPLODED VIEW AND SPARE PART LIST 1. Waterproof caps x4 2. Housing x1 3. Housing x1 4. Insert body x1 5. Nut of spike x1 6. Cable ring x1 7. Conductive copper parts x4 8. Protection box x4 9. Springs x4 10.
- Page 7 WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 2 years for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed.
- Page 8 Manufactured under license of Daewoo International Corporation, Korea...
