- Page 1 DALPRS18-1 LITHIUM PRUNING SHEAR USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1.GENERAL SAFETY INSTRUCTIONS FOR ELECTRIC TOOLS ............3 2. SAFETY REGULATIONS ........................5 3. LAYOUT AND ITEMS SUPPLIED......................4. INTENDED USE ............................9 5. BEFORE STARTING THE EQUIPMENT ....................6. OPERATION.............................10 7. TECHNICAL DATA ..........................13 8. EXPLODED VIEW AND SPARE PARTS LIST ..................14 WARRANTY ............................... -
Page 3: General Safety Instructions For Electric Tools
Fig. 1a Fig.1b... - Page 4 Fig.2a Fig.2b 9 10 Fig.3 Fig.4a 45° Fig.4b Fig.4c...
-
Page 5: Safety Regulations
Fig.5 2. SAFETY REGULATIONS General Power Tool Safety Warnings WARNING: Read all safety warnings and instructions.Failure to follow the warnings and instruc- tions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool”... - Page 6 c) Do not expose power tools to rain or wet conditions. Water entering a power tool wil l increase the risk of electric shock. d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
- Page 7 h) Store idle Appliances Indoors - When not in use, appliances should be stored indoors in dry,and high or locked-up place - out of reach of children. 5) Battery tool use and care a) Replace only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack.
- Page 8 • Always check the blades carefully before operation. • Handle the blades with extreme care to prevent cuts or injury from the blades. • Remove the battery after each use and before attempting to perform inspection or maintenance. • Always wear protective gloves when using, adjusting or cleaning the machine. •...
-
Page 9: Layout And Items Supplied
9.Charging batteries at a temperature below 10°C will cause chemical damage to the cell and may cause a fire. 10.Do not use batteries which have heated during the charging process, as the battery cells may have suffered dangerous damage. 11.Do not use batteries which have suffered curvature or deformation during the charging process or which show other non-typical symptoms (gassing, hissing, cracking,…) 12.Never fully discharge the battery pack (recommended depth of discharge max. -
Page 10: Before Starting The Equipment
5. BEFORE STARTING THE EQUIPMENT 5.1 Installing the battery (Fig. 2a/2b) Press the both side of the battery pack as shown in Fig. 2a and push the battery pack into the mount provided. When the battery pack is positioned as in Fig. 2b, make sure that the battery pack latch in place! To remove the battery pack, proceed in reverse order. - Page 11 blade screw 11(Fig.4a). Remove the blade 1 along 45 ° direction (Fig.4b). To Insert the blade 1, Be careful not to allow any foreign matter to become attached to the blade gear and do not damage it. First Insert part of the tooth of the blade 1 into the case as shown(- Fig.4c), then rotate the blade 1until the hole of the blade 1 is aligned to the hole of the aluminum gearbox.Incorrect location of the blade will damage the machine.
- Page 12 8. Disposal and recycling The unit is supplied in packaging to prevent its being damaged in transit. This packaging is raw material and can therefore be reused or can be returned to the raw material system. The unit and its accessories are made of various types of material, such as metal and plastic. Defective components must be disposed of as special waste.
-
Page 13: Technical Data
7. TECHNICAL DATA Power: 20 V Max cut capacity (fresh branch): 28 mm Cuts dry hard wood per full charge: 8 mm branch: 600 cuts 10 mm branch: 500 cuts 15 mm branch: 150 cuts Blade material: 65 Mn Safety switch: Yes Battery and charger not included •... -
Page 14: Exploded View And Spare Parts List
8. EXPLODED VIEW AND SPARE PARTS LIST... - Page 15 Description qty/unit fixed pruning blade pruning blade screw M8*30 strong magnetic bead Hall board 6pin screw M3*6 screw ST2.9*13 right housing right base of battery pack screw M3*6 inner ring screw M3*6 Bearing ring output disk 14" gear 11" holder 14"...
-
Page 16: Warranty
WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 2 years for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed. - Page 17 Manufactured under license of Daewoo International Corporation, Korea...
