- Page 1 INSTALLATION & CARE GUIDE T W O ‐ P I E C E B A C K O U T L E T T O I L E T June 2012 © 2011 ICERA USA...
-
Page 2: Before You Begin
BEFORE YOU BEGIN Please read these instructions carefully to familiarize yourself with the required tools, materials, and installation sequences. This will help you avoid costly mistakes. In addition, read all operating and safety instructions. All information in this guide is based upon the latest product information available at the time of publication. Icera reserves the right to make changes in product characteristics, packaging, or availability at any time without notice. FIRST STEPS Carefully inspect the new fixture for any sign of damage. Ensure that the toilet flange has the correct rough‐in dimension. This toilet has a 4” rough‐in dimension (distance from the floor to wall flange centerline). Toilet flange should be flush (even) with the wall, within 1/16” (16 mm). Seat post holes are on 5 ½” (140 mm) centers. Shut off the water supply. NOTE: If replacing the supply valve, first shut off the main water supply. ... -
Page 3: Parts Provided
TOOLS AND MATERIALS REQUIRED (not supplied) Adjustable wrench Metal file (file cut) Tape measure Tubing cutter Level Hacksaw Putty knife Screwdriver Toilet installation flange set Toilet gasket / seal (neoprene or felt recommended) Water supply line PARTS PROVIDED Toilet seat Tank lever Installation bolts and caps NOTICE: If the existing toilet does not have a supply shut‐off valve below the tank, install one before installing the new toilet. © 2011 ICERA USA... - Page 4 Installation Guide 1) Install the closet bolts on the flange. Slide them into place, parallel to the floor and 6” (152 mm) apart. (Use putty to hold them in place if needed.) Then, drill the 2 mounting pilot holes on the floor as shown. 2) Install the outlet seal on the flange. Apply sealant around the edge of the toilet’s baseplate facing the wall. © 2011 ICERA USA...
- Page 5 Alternately tighten the nuts until the toilet is firmly mounted to the wall. Do not overtighten the nuts, or the ceramic base may be damaged! 4) After the wall bolts are affixed, proceed to the floor bolt installation. First, put the washers in place on the ceramic base. Then, insert the floor bolts through the mounting holes, and tighten into the pre‐drilled floor holes. 5) Install the 4 bolt caps. If necessary, cut the bolts to length for the caps’ installation. Smooth / clean any excess sealant around the base. © 2011 ICERA USA...
- Page 6 6) Tank installation. Install the gasket at the bottom of the water tank. Install the bolts into the bracket, and tighten evenly. Do not overtighten! Bolt 7) Mounting bolt tabs must contact 8) Connect water supply line, and turn bowl for proper gasket compression. on the water. Flush several times, and check for leaks. Do not overtighten! Bolt tab © 2011 ICERA USA...
- Page 7 Never use an abrasive material such as a brush or scouring pad to clean surfaces. • If you live in a hard water area, make certain that the holes in the toilet rim are kept clean to ensure proper bowl flushing. © 2011 ICERA USA...
-
Page 8: Troubleshooting Guide
Adjust the tank water level if it is too high. to enter the tank • Replace the fill valve if the valve float sinks. • Tank takes excessive Fully open the water supply shut‐off valve. • time to fill Check supply line for a kink. Remove kink. • Clean valve inlet, valve head, or supply line. Flush lines. • There is excessive Partially close the water supply shut‐off valve if the noise when the tank is water pressure to the toilet is too high. Check the toilet filling performance following any such adjustment. • Remove dirt or obstructions from the valve head. Flush the lines. FOR ANY INSTALLATION OR SERVICE ISSUES, PLEASE CONTACT: Icera USA 531 Main Street, Unit 860 El Segundo, California 90245 Toll Free: (855) 444‐2372 service@icerausa.com © 2011 ICERA USA...
