Page 1
We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
Table of Contents Table of Contents ............2 Pre-Assembly ..............2 Warranty ................. 2 Planning Assembly ..............2 What is Covered ...............2 Hardware Included ..............2 What is Not Covered ..............2 Package Contents ..............3 Assembly ............... 4 Care and Cleaning ............6 Warranty 2 YEAR FRAME WARRANTY WHAT IS COVERED...
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Table top Table leg Leg connector HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
Assembly Attaching the legs to the table top Lay down the table top (A) on a soft surface. Assemble the table legs (B) together with the table top (A). Repeat this step 3 times to connect the other 3 table legs.
Page 5
Assembly (continued) Connecting the central ring to the legs Place the leg connector (C) in the middle of four table legs (B). Keep the screw holes straight and x the leg connector (C) and the table legs (B) with M6x28 combination bolts (AA) by using hex wrench (BB) Loosely tighten all bolts.
Assembly (continued) Tightening all bolts Tighten all the M6x28 combination bolts (AA) by using the hex wrench (BB). Turn the table right side up. Ensure all connections are secure before use. Care and Cleaning For best results, clean the frame with a damp cloth, and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate.
Page 7
Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
