Page 1
We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
Page 2
Table of Contents Pre-Assembly ..............3 Table of Contents ............2 Planning Assembly ..............3 Safety Information ............2 Hardware Included ..............3 Product Caution ..............2 Safety Warnings ..............2 Package Contents ..............4 Warranty ................ 2 Assembly ............... 5 Care and Cleaning ............
Page 3
Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non- abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to complete the assembly of this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size.
Page 4
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Table top Table leg Leg connector...
Page 5
Assembly Attaching the legs to the table top Lay down the table top (A) on a soft surface. Slide the table legs (B) into the table top (A). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
Page 6
Assembly (continued) Connecting the leg connector to the legs Place the leg connector (C) in the middle of the four table legs (B). Attach the leg connector (C) to the table legs (B) with M6x28 combination bolts (AA) by using the hex wrench (BB) Loosely tighten all bolts.
Page 7
Assembly (continued) Tightening all bolts Tighten all the M6x28 combination bolts (AA) by using the hex wrench (BB). Turn the table right side up. Ensure all connections are secure before use. Care and Cleaning For best results, clean the frame with a damp cloth, and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate.
Page 8
Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
