Using Your Cooktop
Fig 11 Cooktop Layout
1. Semi-rapid burner
2. Triple-ring wok burner
3. Dual burner
Gas Burners
The knob controls the flow of gas through the safety tap.
= closed valve
= maximum aperture or flow
https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGX2/User_Guide_OR120DDWG...
Updated: Thu, 06 Apr 2023 09:19:00 GMT
Powered by
1
Advertisement
Related Manuals for Fisher & Paykel OR120DDWGX2
Summary of Contents for Fisher & Paykel OR120DDWGX2
- Page 1 1. Semi-rapid burner 2. Triple-ring wok burner 3. Dual burner Gas Burners The knob controls the flow of gas through the safety tap. = closed valve = maximum aperture or flow https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGX2/User_Guide_OR120DDWG… Updated: Thu, 06 Apr 2023 09:19:00 GMT Powered by...
-
Page 2: Before Using Your Cooktop
• Make sure all controls are turned off. Lighting the Cooktop 1. Choose the control knob for the burner you want to use. 2. Press the knob down gently and turn it anticlockwise to the https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGX2/User_Guide_OR120DDWG… Updated: Thu, 06 Apr 2023 09:19:00 GMT Powered by... -
Page 3: Flame Failure Safety Feature
The dual burner is a very flexible burner. It has one inner and two outer crowns. The inner crown can be controlled separately from the flames of the outer crowns. https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGX2/User_Guide_OR120DDWG… Updated: Thu, 06 Apr 2023 09:19:00 GMT Powered by... - Page 4 To use the inner crown, adjust the flame anywhere between the . Do not adjust the flame between and OFF. To use the inner and outer crowns together, adjust the flame anywhere between the https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGX2/User_Guide_OR120DDWG… Updated: Thu, 06 Apr 2023 09:19:00 GMT Powered by...
-
Page 5: If The Cooktop Does Not Light
Use flat-bottomed pans, and make sure that they match your burner, as shown in the following table. A small pot on a large burner is not efficient. Diameters of Pans which may be Used on Cooktop Burners Minimum Maximum Semi-Rapid 16 cm 24 cm https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGX2/User_Guide_OR120DDWG… Updated: Thu, 06 Apr 2023 09:19:00 GMT Powered by... - Page 6 Triple Ring Wok Maximum diameter for wok pans: 36 cm Fig. 15 Correct and incorrect matching Fig. 16 Efficient and inefficient saucepan bottoms Wok Stand Fig. 17 Correct placement of wok stand https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGX2/User_Guide_OR120DDWG… Updated: Thu, 06 Apr 2023 09:19:00 GMT Powered by...
- Page 7 • Always use the wok stand for wok cooking. • Do not use the wok stand for other saucepans. • Only use the wok stand on the dual or triple-ring wok burners. https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGX2/User_Guide_OR120DDWG… Updated: Thu, 06 Apr 2023 09:19:00 GMT Powered by...
