Care & Cleaning
DOS
• Read these cleaning instructions and the 'Safety and warnings'
section before you start cleaning your cooker.
• Before cleaning or removing any part, make sure that
everything on the cooker has been turned off.
• Unless suggested otherwise in the chart following, allow any
part to cool to a safe temperature before cleaning. If you do
need to handle a warm or hot part, take extreme care. Wear
long protective mitts to avoid burns from steam or hot surfaces.
• Try using any cleaner on a small area first, to ensure it doesn't
stain.
• See the pages following this chart for instructions on removing
and replacing different parts of the cooker for cleaning or
maintenance.
• To help you identify any parts, see illustrations in section
'Introduction' and after this cleaning chart.
• Ensure the anti-tip device is re-engaged if you move the cooker
for cleaning. Failure to do this may result in the oven tipping,
and adults and children may be killed.
• To prevent soiling from becoming 'baked on' and stubborn, we
recommend removing any easy-to-reach spills, food or grease
stains from the oven cavity enamel after each use.
https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SCI1X1/User_Guide_OR90SCI1X1/07_...
DON'TS
• Do not use aerosol cleaners until the
cooker has completely cooled. The
propellant substance in these
cleaners could catch fire in the
presence of heat.
• Do not let soiling or grease
accumulate anywhere in or on the
cooker. This will make future cleaning
more difficult and may present a fire
hazard.
• Do not use any abrasive or harsh
cleaners, cloths, scouring pads or
steel wool. These will scratch your
cooker and damage its appearance.
• Do not use a steam cleaner to clean
any part of the cooker.
• Do not perform any cleaning or
maintenance on parts not specifically
named in the chart below. If in doubt,
contact Customer Care.
Updated: Wed, 12 Apr 2023 02:30:58 GMT
Powered by
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the OR90SCI1X1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Fisher & Paykel OR90SCI1X1

  • Page 1 • To prevent soiling from becoming ‘baked on’ and stubborn, we contact Customer Care. recommend removing any easy-to-reach spills, food or grease stains from the oven cavity enamel after each use. https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SCI1X1/User_Guide_OR90SCI1X1/07_… Updated: Wed, 12 Apr 2023 02:30:58 GMT Powered by...
  • Page 2: Manual Cleaning Chart

    (exterior) or glass cleaner. Oven Parts Enamel oven interior – light 1. Wipe with a damp cloth and a • To prevent soiling from becoming ‘baked on’ soiling https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SCI1X1/User_Guide_OR90SCI1X1/07_… Updated: Wed, 12 Apr 2023 02:30:58 GMT Powered by...
  • Page 3 If it accidentally does, remove soiling 3. Apply an ammonia-based immediately cleaner or oven cleaner following the cleaner. manufacturer’s instructions. 4. After cleaning, replace the side racks and shelves. https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SCI1X1/User_Guide_OR90SCI1X1/07_… Updated: Wed, 12 Apr 2023 02:30:58 GMT Powered by...
  • Page 4 (interior) from the enamel after each use 2. Wipe dry with a soft cloth. https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SCI1X1/User_Guide_OR90SCI1X1/07_… Updated: Wed, 12 Apr 2023 02:30:58 GMT Powered by...
  • Page 5 Take extreme care. 4. Follow steps 2 to 4 for ‘Everyday soiling on glass’ https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SCI1X1/User_Guide_OR90SCI1X1/07_… Updated: Wed, 12 Apr 2023 02:30:58 GMT Powered by...
  • Page 6 • Before removing the door, make sure there is a large enough clear, protected surface in the kitchen to rest the door on. • Take care, the oven door is heavy! https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SCI1X1/User_Guide_OR90SCI1X1/07_… Updated: Wed, 12 Apr 2023 02:30:58 GMT Powered by...
  • Page 7 2. Open the levers fully on both sides. 3. Holding the door firmly on both sides, gently close it 4. Disengage the hinges and remove the door. Place on about halfway. a protected surface. https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SCI1X1/User_Guide_OR90SCI1X1/07_… Updated: Wed, 12 Apr 2023 02:30:58 GMT Powered by...
  • Page 8 • If the glass feels difficult to remove or replace, do not force it. Call your Authorised Repairer or Customer Care for help. Service visits providing assistance with using or maintaining the oven are not covered by your warranty. https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SCI1X1/User_Guide_OR90SCI1X1/07_… Updated: Wed, 12 Apr 2023 02:30:58 GMT Powered by...
  • Page 9 Open the latches securing the lower trim to the base of the oven door: 1. Loosen the inner and outer screws securing each of the latches by two turns. • Do not loosen the middle screw. • Do not fully remove the screws. https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SCI1X1/User_Guide_OR90SCI1X1/07_… Updated: Wed, 12 Apr 2023 02:30:58 GMT Powered by...
  • Page 10 • You replace all parts correctly, as shown on the following page. • The inner pane must be in the position described below in order to fit into the door and to ensure that the oven https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SCI1X1/User_Guide_OR90SCI1X1/07_… Updated: Wed, 12 Apr 2023 02:30:58 GMT...
  • Page 11 • Make sure the glass is facing the same way as when you removed it form the door. • You should be able to read the wording on it as it faces you. https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SCI1X1/User_Guide_OR90SCI1X1/07_… Updated: Wed, 12 Apr 2023 02:30:58 GMT...
  • Page 12 3. Gently push the lower trim back onto the door glass until it clicks into place. Make sure the lower trim is fitted correctly and firmly in place and that the glass panes are secure. https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SCI1X1/User_Guide_OR90SCI1X1/07_… Updated: Wed, 12 Apr 2023 02:30:58 GMT...
  • Page 13 4. Slide the two latches back into place on the base of the lower trim. 5. Re-tighten the screws so that the latches and the lower trim are firmly secured. https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SCI1X1/User_Guide_OR90SCI1X1/07_… Updated: Wed, 12 Apr 2023 02:30:58 GMT Powered by...
  • Page 14 1. Hold the door firmly in an approximately halfway open 2. Insert the hinge tongues into the slots, making sure position. that the notches on both sides drop into place as shown. https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SCI1X1/User_Guide_OR90SCI1X1/07_… Updated: Wed, 12 Apr 2023 02:30:58 GMT Powered by...
  • Page 15 Remove All Shelves 1. Slide out all shelves and remove. For easier access we recommend removing the oven door. See ‘Removing and refitting the oven door’. Remove all shelves https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SCI1X1/User_Guide_OR90SCI1X1/07_… Updated: Wed, 12 Apr 2023 02:30:58 GMT Powered by...
  • Page 16 3. Remove the side racks. and remove the fixing screws. To Replace the Side Racks 1. Make sure the side racks are the right way up, as 2. Refit the fixing screws and tighten. https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SCI1X1/User_Guide_OR90SCI1X1/07_… Updated: Wed, 12 Apr 2023 02:30:58 GMT Powered by...
  • Page 17 • When you have finished cleaning the oven ceiling, raise the grill element and screw the element fixing screws back onto the studs. Make sure that the fixing screws are tightened and the element is held securely in place. • The grill element itself is self-cleaning. https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SCI1X1/User_Guide_OR90SCI1X1/07_… Updated: Wed, 12 Apr 2023 02:30:58 GMT Powered by...
  • Page 18: Replacing An Oven Light Bulb

    8. Replace the lamp cover: for upper lights, turn it clockwise to tighten and then back a quarter turn. 9. Turn the power supply to the cooker back on at the main fuse or circuit breaker panel. https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SCI1X1/User_Guide_OR90SCI1X1/07_… Updated: Wed, 12 Apr 2023 02:30:58 GMT...
