mk-dent EM1190K Instruction Manual

Intended use

The electric motor is intended for the electric drive of dental straight and contra-angled handpieces
used in the preparation of cavity and / or crowns.

Important Details

The MK-dent Electric Motor (EM1190K)
- is only intended for dental treatment of patients.
- is according to relevant national regulations as a medical device.
These provisions indicate, that
- applicable accident prevention regulations and health and safety regulations must be observed.
- only a competent user is allowed to use the product according to this instruction.
- only faultless work equipment is to be used.
- any contamination from the product must be avoided.
- patients, users and third parties are to be protected from danger.

Risks from electromagnetic Fields

When treating patients with cardiac pacemakers or comparable implanted systems it must be expected that electromagnetic
fields will influence the functioning of the implanted systems. Before beginning of the treatment, the user must be question the
patient accordingly.

Technical Facts

MK-dent Electric Motor EM1190K
Motor Voltage:
RPM:
Torque:
Operating Mode:
Operating Voltage
of LED:

Meaning of Symbols

REF
Item No.
Guidance and manufacturer´s declaration - electromagnetic emission
The electric micromotors are intended for use in the electromagnetic environment specified below. The customer or the user of
the electric micromotors should assure, that it is used in such an environment.
Emission Test
RF emissions CISPR 11
RF emissions CISPR 11
Harmonic emissions
IEC 61000-3-2
Voltage fluctuations/
flicker emissions IEC 61000-3-3
min. 1,6 - 2,5 V DC, max. 26 V DC
min. 450min , max. 40.000 min
-1 -1
max. 2,8 Ncm
Intermittend Duty 2 min on, 5 min off
3,0 - 3,5 V DC (recommended: 3,2 V DC)
SN
Serial No.
Compliance
Group 1
Class B
Class A
Complies
Air Cooling:
Cooling Capacity:
Air Out Motor Coupling:
Air Pressure of Spray Cooling: 1,0 - 2,4 bar (14.5 - 34.8 psi)
Spray Pressure:
Caution!
Elecromagnetic Environment - Guidance
The dental electrical micromotors use RF energy only for its inter-
nal function. Therefore, its RF emissions are very low and are not
likely to cause any interference in nearby electronic equipment.
The dental electrical micromotors are suitable for use in all
establishments other than domestic and those directly connected
to the public low-voltage power supply network that supplies
buildings used for domestic.
- 1 -
Instruction manual
EM1190K
2,4 - 4,6 bar (34.8 - 66.7 psi)
31 ± 5 NL/min.
7,6 ± 1,5 NL/min.
0,9 - 2,0 bar (13.0 - 29.0 psi)
0123
CE-Sign
0123
