Teradek Bolt 6 LT Quick Start Manual

Hide thumbs Also See for Bolt 6 LT:

Advertisement

Quick Links

Bolt 6 LT Quick Start Guide | Bolt 6 | Teradek User Guide
Teradek User Guide
Teradek User Guide
Bolt 6 LT Quick Start Guide
Updated on Oct 06, 2022
The Bolt 6 LT Set is a real-time wireless video transmission system that
supports 4K video with Teradek's patented Zero-Delay technology, now with
less interference using the newly opened 6GHz wireless frequency. Bolt 6 LT
can send and receive color-accurate, True-HDR videos in under 0.001
seconds using the set's included Bolt 6 LT video Transmitter and Receiver.
Bolt 6 LT is cross-compatible with the entire Bolt 4K Series - including Bolt
4K, Bolt 4K LT, and the Bolt 4K Monitor Modules - giving you the option to
expand your workflow requirements. Link up to 6 receivers to one transmitter,
or unlimited receivers when used in Broadcast Mode (available on MAX
models).

Table of Contents

1.
2.
3.
4.
5.
6.
7.
Wireless Settings
◦
◦
Tools
◦
1 von 14
/
Bolt 6
/
Quick Start Guides
https://guide.teradek.com/a/1604143-bolt-6-lt-quick-start-guide
22.02.23, 21:26

Advertisement

loading
Need help?

Need help?

Do you have a question about the Bolt 6 LT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Teradek Bolt 6 LT

Summary of Contents for Teradek Bolt 6 LT

  • Page 1: Table Of Contents

    Bolt 6 LT video Transmitter and Receiver. Bolt 6 LT is cross-compatible with the entire Bolt 4K Series – including Bolt 4K, Bolt 4K LT, and the Bolt 4K Monitor Modules – giving you the option to expand your workflow requirements.

  • Page 2: What's Included

    Bolt 6 LT Quick Start Guide | Bolt 6 | Teradek User Guide https://guide.teradek.com/a/1604143-bolt-6-lt-quick-start-guide Advanced/System Settings ◦ Additional Information ◦ BOLT APP OTHER RESOURCES What's Included • Bolt 6 LT Transmitter and Receiver • Hot Shoe Adaptor • Lightstand Adapter 1/4-20in •...

  • Page 3: Power And Connect

    Bolt 6 LT Quick Start Guide | Bolt 6 | Teradek User Guide https://guide.teradek.com/a/1604143-bolt-6-lt-quick-start-guide Power and Connect 1. Connect your power source to the transmitter and receiver using the included A/C adapter. If both devices are equipped with battery plate accessories, attach a compatible battery (Gold or V mount).
  • Page 4 Bolt 6 LT Quick Start Guide | Bolt 6 | Teradek User Guide https://guide.teradek.com/a/1604143-bolt-6-lt-quick-start-guide enabled. PAIRING/UNPAIRING VIA FRONT PANEL Pair: 1. Using the Menu Joystick, navigate to the Pair menu on both the transmitter and the receiver front panel. 2. Select Pair to begin the pairing process. The transmitter will begin scanning for a receiver within range and automatically pair to the receiver.

  • Page 5: Power Cables

    Bolt 6 LT Quick Start Guide | Bolt 6 | Teradek User Guide https://guide.teradek.com/a/1604143-bolt-6-lt-quick-start-guide WIRED PAIRING VIA BOLT MANAGER To Pair: 1. Connect both the transmitter and receiver(s) to your computer (Windows/Mac) via USB. 2. Open Bolt Manager, select the Pairing tab, then tap the Wired Pairing button.

  • Page 6: Mounting

    TX unit. Mounting WITHOUT DUAL MOUNT Bolt 6 LT devices have a 1/4”-20 threaded hole and two M3 threaded holes on the bottom for mounting the included light stand adapter or any other mounting accessory. " CAUTION: DO NOT OVERTIGHTEN SCREWS INSERTED INTO THE THREADED HOLES.

  • Page 7: Tx/Rx Configuration Menus

    To achieve even better range performance, attach the receiver to your Bolt Panel Antenna while in Broadcast Mode. NOTE: Bolt 6 LT 750 and 1500 receivers will not link to a Bolt 6 LT MAX transmitter in Broadcast 7 von 14...

  • Page 8: Video Settings

    Bolt 6 LT Quick Start Guide | Bolt 6 | Teradek User Guide https://guide.teradek.com/a/1604143-bolt-6-lt-quick-start-guide Mode, even if they were previously paired. You must use a Bolt 6 LT MAX receiver. Otherwise, the transmitter's OLED will display Broadcast Not Supported. Enable Fixed Frequency - Fixed Frequency Mode allows your transmitter to designate a specific non-DFS channel within the selected wireless region for use, providing a stronger connection in difficult environments.
  • Page 9 Bolt 6 LT Quick Start Guide | Bolt 6 | Teradek User Guide https://guide.teradek.com/a/1604143-bolt-6-lt-quick-start-guide Video OSD Settings (RX Only) - Choose when to display the OSD. ◦ Never show ◦ Show when operating ◦ Show when no video ◦ Always show Display Settings - Use the Display Settings to control the OLED display operation.
  • Page 10 Bolt 6 LT Quick Start Guide | Bolt 6 | Teradek User Guide https://guide.teradek.com/a/1604143-bolt-6-lt-quick-start-guide • Press and hold the menu joystick upward for 5 seconds. To unlock, press and hold the menu joystick upwards for five seconds or until the display reads "KEYPAD UNLOCKED."...
  • Page 11 Bolt 6 LT Quick Start Guide | Bolt 6 | Teradek User Guide https://guide.teradek.com/a/1604143-bolt-6-lt-quick-start-guide Additional Information Device Info - Displays the model and serial number of the device Firmware Versions - Displays the current firmware versions for all device components.
  • Page 12 Bolt 6 LT Quick Start Guide | Bolt 6 | Teradek User Guide https://guide.teradek.com/a/1604143-bolt-6-lt-quick-start-guide • Settings (Descriptions listed in Transmitter Menu section) - Tap the settings button on the top right corner of the screen to customize the transmitter’s various settings.
  • Page 13 Bolt 6 LT Quick Start Guide | Bolt 6 | Teradek User Guide https://guide.teradek.com/a/1604143-bolt-6-lt-quick-start-guide • Settings (Descriptions listed in Receiver Menu section) - Tap the settings button on the top-right corner of the display to customize the receiver’s various settings such as the output format, audio, display, and OSD.
  • Page 14 Bolt 6 LT Quick Start Guide | Bolt 6 | Teradek User Guide https://guide.teradek.com/a/1604143-bolt-6-lt-quick-start-guide ◦ Temperature Quick Start Guides ◦ Camera Recording Bolt 6 XT Quick Start Guide ◦ Bandwidth Bolt 6 LT Quick Start Guide ◦ Region Bolt 6 LT-HDMI Quick Start Guide ◦...
