- Page 1 IM3124 12/2022 REV02 DIGISTEEL 355S, 425S, 505S OPERATOR’S MANUAL ENGLISH Lincoln Electric Bester Sp. z o.o. ul. Jana III Sobieskiego 19A, 58-260 Bielawa, Poland...
-
Page 2: Table Of Contents
12/05 THANKS! For having choosen the QUALITY of the Lincoln Electric products. Please Examine Package and Equipment for Damage. Claims for material damaged in shipment must be notified immediately to the dealer. For future reference record in the table below your equipment identification information. Model Name, Code & Serial Number can be found on the machine rating plate. -
Page 3: Technical Specifications
Technical Specifications NAME INDEX DIGISTEEL 355S W000404454 DIGISTEEL 425S W000404455 DIGISTEEL 505S W000404456 INPUT Input Voltage U EMC Class Frequency 355S 425S 400V ± 15% 3-phase 50/60Hz 505S Input Power at Rated Cycle Input Amperes I 1max 15 kVA @ 50% Duty Cycle 355S 0,90 (40°C) - Page 4 RECOMMENDED INPUT CABLE AND FUSE SIZES Fuse Type: Time-Delay or Circuit Breaker Type D Power Lead 400V 355S 4 Conductor, 2,5mm 425S 4 Conductor, 4,0 mm 505S 4 Conductor, 4,0 mm DIMENSION Weight Height Width Length 355S 68kg 425S 78kg 932 mm 560 mm 925 mm...
-
Page 5: Eco Design Information
ECO design information The equipment has been designed in order to be compliant with the Directive 2009/125/EC and the Regulation 2019/1784/EU. Efficiency and idle power consumption: Efficiency when max power consumption Index Name Equivalent model / Idle power consumption W000404454 DIGISTEEL 355S 86,7% / 29W No equivalent model... - Page 6 Typical gas usage for MIG/MAG equipment: DC electrode positive Wire Wire Feeding Gas flow Material type diameter Shielding Gas Current Voltage [m/min] [l/min] [mm] Carbon, low 0,9 ÷ 1,1 95 ÷ 200 18 ÷ 22 3,5 – 6,5 Ar 75%, CO alloy steel Aluminium 0,8 ÷...
-
Page 7: Electromagnetic Compatibility (Emc)
This machine has been designed to operate in an industrial area. The operator must install and operate this equipment as described in this manual. If any electromagnetic disturbances are detected the operator must put in place corrective actions to eliminate these disturbances with, if necessary, assistance from Lincoln Electric. WARNING Provided that the public low voltage system impedance at the point of common coupling is lower than: ... -
Page 8: Safety
Failure to follow the instructions in this manual could cause serious personal injury, loss of life, or damage to this equipment. Read and understand the following explanations of the warning symbols. Lincoln Electric is not responsible for damages caused by improper installation, improper care or abnormal operation. - Page 9 CYLINDER MAY EXPLODE IF DAMAGED: Use only compressed gas cylinders containing the correct shielding gas for the process used and properly operating regulators designed for the gas and pressure used. Always keep cylinders in an upright position securely chained to a fixed support. Do not move or transport gas cylinders with the protection cap removed.
-
Page 10: Intoduction
Intoduction DIGISTEEL 355S, 425S, 505S inverter sources have to The complete packaging includes the following items: be connected with wire feeders WF 52D and WF 56D. Inverter source; Signal from the power source will be displayed on wire USB with Operator’s Manual;... - Page 11 Output Connections Refer to points [2], [3] and [4] of the figures below. Controls and Operational Features Figure 1. Figure 2. 1. Power Switch ON/OFF (I/O): Controls the input power. Make sure the power source is properly connected to 8. Supply Plug: for gas heater kit (see “Accessories the mains supply before turning power on ("I").
- Page 12 17. Quick Connect Coupling: Coolant inlet Water Cooler Connection (supplies cool coolant to the torch/gun). DIGISTEEL 355S, 425S, 505S work with the water cooler ® COOL ARC 26 (see "Accessories Suggested" chapter). 18. Quick Connect Coupling: Coolant outlet (takes warm coolant from torch/gun). WARNING Read the cooler manual before connecting 19.
- Page 13 Transport & Lifting Maintenance WARNING WARNING For any repair operations, modifications or maintenances, it is recommended to contact the nearest Technical Falling equipment can cause injury and damage to unit. Service Center Lincoln Electric. Repairs modifications performed by unauthorized service or personnel will cause, that the manufacturer’s warranty will be lost.
- Page 14 Electric for advice or information about their use of our products. We respond to our customers based on the best information in our possession at that time. Lincoln Electric is not in a position to warrant or guarantee such advice, and assumes no liability, with respect to such information or advice.
-
Page 15: Weee
12/05 Part List reading instructions Do not use this part list for a machine if its code number is not listed. Contact the Lincoln Electric Service Department for any code number not listed. Use the illustration of assembly page and the table below to determine where the part is located for your particular code machine. -
Page 16: Accessories Suggested
Accessories Suggested W000404460 WF 52D W000404461 WF 56D K14182-1 COOLARC-26 W000010167 FREEZCOOL 9,6L GRD-400A-70-xM* Ground cable 400A/70 mm²; x=5/10/15 m K14196-1 OUTPUT CONNECTION KIT (350A) K14202-1 OUTPUT CONNECTION KIT (500A) K14201-1 CABLE MANAGEMENT KIT K14208-1 WATER CONNECTION KIT K14176-1 GAS HEATER KIT INTERCONNECTION CABLE K14198-PG CABLE PACK 5PIN G 70MM2 1 M... -
Page 17: Connection Diagram
Connection Diagram ® COOLARC 26 K14182-1 WF 52D W000404460 WF 56D W000404461 K14198-PG K14198-PG-XM K14199-PGW K14199-PGW-XM DIGISTEEL 355S W000404454 DIGISTEEL 425S W000404455 DIGISTEEL 505S W000404456 Figure 6 English English...
