  • Page 1 1, 2, & 4 Corona Discharge Ozone Generators INSTALLATION & OPERATION MANUAL P/N: 4-0308 Rev. G...

  • Page 2: Table Of Contents

    DEL Eclipse 1, 2, & 4 Corona Discharge Ozone Generators Table of Contents SECTION 1 SECTION 4 General Information Maintenance & Service 4A System Electromechanical Overview .......3 1A Description ...............1 1B Specifi cations ............1 4B System Maintenance ..........3 1C Warranty Summary ..........1 4C Generator Servicing ..........3...

  • Page 3: General Information

    DEL Eclipse 1, 2, & 4 Corona Discharge Ozone Generators SECTION 1 General Information General Information SECTION 2 Installation Installation 1A Description 2A Location The DEL Eclipse Corona Discharge (CD) series ozone The DEL Eclipse units are designed for wall mounting. See generators described in this manual are designed to provide Figure 1.

  • Page 4: Plumbing

    DEL Eclipse 1, 2, & 4 Corona Discharge Ozone Generators 2D Plumbing Ozone gas is introduced to the pool circulation line using a venturi injector. Suction developed by the venturi allows the DEL Eclipse generator to operate safely under vacuum.

  • Page 5: System Shut-Down

    DEL Eclipse 1, 2, & 4 Corona Discharge Ozone Generators 4B-3. Regularly reinstall and check the fl owmeter for proper Rigid Injector Manifold: This Manifold is equipped with fl ow. Always remove the fl ow meter after confi rming a DELCheck spring loaded valve.

  • Page 6: Trouble Shooting

    DEL Eclipse 1, 2, & 4 Corona Discharge Ozone Generators Top Endcap- Remove back Power Supply screws only Ozone Electrode Module #2 Support Nut Top View Electrode Ozone Support Bracket Module #1 (Do not remove) Bottom Endcap- Remove front screws only...

  • Page 7: Replacement Parts And Ordering Information

    DEL Ozone warrants that it or its authorized dealers will repair or replace, at its option, any part of such products proven to be defective in materials or workmanship within ONE (1) year from the date of retail purchase of such products.
