  • Page 3 FRANKFURT iller Lass deine Signale fließen, natürlich und kraftvoll wie ein Fluss! Die River Series verkörpert diesen Anspruch bis ins Detail: Mit hochpräzisen Schaltungen, designt von unseren preisgekrönten Ingenieuren, damit dein Sound unver- fälscht sein Ziel erreicht: das Herz deiner Zuhörer.
  • Page 4: Bestimmungsgemässer Gebrauch

    BEDIENUNGSANLEITUNG iller 1-Kanal Line Isolation Box passiv BESTIMMUNGSGEMÄSSER GEBRAUCH Bei dem Produkt handelt es sich um ein Gerät für die Veranstaltungstechnik, sowie Studio, TV und Broadcast! Das Produkt ist für den professionellen Einsatz im Bereich der Veranstaltungstechnik, sowie Studio, TV und Broad- cast entwickelt worden und ist nicht für die Verwendung in Haushalten geeignet! Weiterhin ist dieses Produkt nur für qualifizierte Benutzer mit Fachkenntnissen im Umgang mit Veranstaltungstechnik, sowie Studio, TV und Broadcast vorgesehen!
  • Page 5 BEDIENUNGSANLEITUNG iller 1-Kanal Line Isolation Box passiv ANSCHLÜSSE 1. INPUT Line-Eingang mit Combo-Buchse (XLR / 6,3 mm Klinke), der sowohl für unsymmetrische als auch für symmetrische Verkabelung geeignet ist. Verwenden Sie ein abgeschirmtes Audiokabel, um beispielsweise ein Keyboard an der Line Isolation Box anzuschließen.
  • Page 6 BEDIENUNGSANLEITUNG VERKABELUNGSBEISPIEL balanced or balanced or unbalanced signal unbalanced same level as input signal no ground loop hum...
  • Page 7 BEDIENUNGSANLEITUNG TECHNISCHE DATEN ALLGEMEIN Artikelnummer PILLER Produktart Line Isolator Anzahl Kanäle passiv Übertrager isoliert Anzahl Eingänge Eingangstyp symmetrisch/unsymmetrisch Eingangsanschlüsse 6,3 mm Klinke, XLR Anzahl Ausgänge Ausgangstyp symmetrisch/unsymmetrisch Ausgangsanschlüsse Ground/Lift Schalter Gehäuse Aluminium Strangguss Abmessungen (H/B/T) 110 x 50 x 50 mm Gewicht 0,3 kg Umgebungstemperatur im Betrieb...
  • Page 8 BEDIENUNGSANLEITUNG...
  • Page 9: Ce-Konformitätserklärung

    BEDIENUNGSANLEITUNG ENTSORGUNG VERPACKUNG: HERSTELLERERKLÄRUNGEN 1. Verpackungen können über die üblichen Herstellergarantie & Haftungsbeschränkung Entsorgungswege dem Wertstoffkreislauf Adam Hall GmbH zugeführt werden. Adam-Hall-Str. 1 D-61267 Neu Anspach 2. Bitte trennen Sie die Verpackung ent- sprechend der Entsorgungsgesetze und E-Mail. Info@adamhall.com / +49 (0)6081 / 9419-0. Wertstoffverordnungen in Ihrem Land.
  • Page 10 FRANKFURT iller Let your signals flow, naturally and powerfully like a river! The River Series embodies this claim down to the last detail: featuring high-precision circuits, designed by our award-winning engineers to ensure your sound reaches its destination – the hearts of your listeners.
  • Page 11: Intended Use

    USER MANUAL iller 1-Channel Line Isolation Box passive INTENDED USE This product is a device for event technology, as well as studio, TV and broadcast! This product has been developed for professional use in the fields of event technology, studio, TV and broadcast. It is not suitable for household use! Furthermore, this product is only intended for qualified users with specialist knowledge of event technology, as well as studio, TV and broadcast!
  • Page 12 USER MANUAL iller 1-Channel Line Isolation Box passive CONNECTIONS 1. INPUT Line input with combo jack (XLR / 6.3 mm jack) suitable for both unbalanced and balanced cabling. Use a shielded audio cable to connect, for example, a keyboard to the Line Isolation Box. 2.
  • Page 13: Wiring Example

    BEDIENUNGSANLEITUNG WIRING EXAMPLE balanced or balanced or unbalanced signal unbalanced same level as input signal no ground loop hum...
  • Page 14: Technical Data

    USER MANUAL TECHNICAL DATA GENERAL Product number PILLER Product type Line Isolator No. of channels Type passive Transformer isolated No. of inputs Input type symmetrical/asymmetrical Input connections 6.3 mm Jack, XLR No. of outputs Output type symmetrical/asymmetrical Output connections Ground/lift switch Housing Aluminium continuous casting Dimensions (H/W/D)
  • Page 15 USER MANUAL...
  • Page 16 USER MANUAL DISPOSAL PACKAGING: MANUFACTURER’S DECLARATIONS 1. Packaging can be fed into the reusable Manufacturer's warranty & limitation of liability material cycle using the usual disposal Adam Hall GmbH methods. Adam-Hall-Str. 1 61627, Neu-Anspach, Germany 2. Please separate the packaging in accordance with disposal laws and recycling regulations in Email: Info@adamhall.com / +49 (0)6081 / 9419-0.
