Table Of Contents - Intellian s130N Installation & Operation User Manual

Table of Contents

Chapter 1. Precautions
1.1 Warnings, Cautions, and Notes
1.2 General Precautions
Chapter 2. Certifications
Chapter 3. Introduction
3.1 Introduction of s130N
3.2 Features of s130N
Chapter 4. Planning Installation
4.1 Selection of Installation Site
4.1.1 Minimize Satellite Blockage
4.1.2 Avoid RF Interference
4.2 System Package
4.2.1 Above Deck Unit (ADU)
4.2.2 Antenna Control Unit (ACU)
4.2.3 Multi Switch Module (MSM)
4.2.4 Packing List
4.3 System Cables (Customer Supplied)
4.3.1 RF Cables (Customer Supplied)
4.3.2 Gyrocompass Cable (Customer Furnished)
4.4 Unpacking System Package
Chapter 5. Installing Above Deck Unit (ADU)
5.1 Antenna Dimensions
5.2 Antenna Mounting Hole Pattern
5.3 Designing Mast (Example Only)
5.4 Routing RF Cable on Mast (Example Only)
5.5 Removing Antenna from Wooden Pallet
5.6 Moving Antenna Above Mast
5.7 Mounting Antenna on Mast
5.8 Connecting RF Cable to Antenna
Chapter 6. Installing Below Deck Unit
6.1 Selection of BDU Installation Site
6.2 ACU Dimensions
6.3 MSM Dimensions
6.4 Mounting ACU/MSM
6.5 System Configurations
6.5.1 Single Antenna System Configuration
6.5.2 Dual Antenna System Configuration (Optional)
6.6 BDU Cable Connection
6.6.1 ACU Back Panel Connectors
6.6.2 MSM Back Panel Connectors
6.6.3 ACU Connector Pinout Guide
3
Table of Contents
7
7
7
8
11
11
12
13
13
13
14
15
15
16
16
17
18
18
18
19
21
21
23
24
26
27
29
30
32
35
35
35
36
37
38
38
39
40
40
40
41
