Linear Technology DC2001A Demo Manual page 5

parts List
ITEM QTY REFERENCE
Hardware: For Demo Board Only
2 1 JP1
3 1 JP2
8 2 JP1, JP2
1 11 E1-E2, E5, E7-E13, E17
4 8 E3-E4, E6, E14-E16, E18-E19
6 8 E3-E4, E6, E14-E16, E18-E19
7 8 E3-E4, E6, E14-E16, E18-E19
5 16 E3-E4, E6, E14-E16, E18-E19 (×2)
9 4 MH1, MH2, MH3, MH4
DEMO MANUAL DC2001A
PART DESCRIPTION
HEADER, 4-PIN, 2mm
HEADER, 3-PIN, 2mm
SHUNT
TURRET
STUD, TEST PIN
LUG RING, #10
WASHER, #10 TIN PLATED BRASS
NUT, BRASS 10-32
STANDOFF, SNAP-ON
MANUFACTURER/PART NUMBER
SULLINS, NRPN041PAEN-RC
SULLINS, NRPN031PAEN-RC
SAMTEC, 2SN-BK-G
MILL-MAX, 2501-2-00-80-00-00-07-0
PEM, KFH-032-10
KEYSTONE, 8205
ANY #10 EXT BZ TN
ANY #10-32
KEYSTONE, 8834
