Thank you very much for choosing the Yoshitake's product. To ensure the correct and safe use of the
product, please read this manual before use. This manual shall be kept with care for future references.
The symbols used in this manual have the following meanings.
Warning
Caution
1. Usage of the Product ·················································· 1
2. Specifications ···························································· 1
3. Dimensions and Weights ············································· 2
4. Operation ······························································· 3
5. Maximum Continuous Discharge Capacity ······················ 4
7. Operating Procedure ················································· 10
PRODUCT MANUAL
This symbol indicates a potentially hazardous situation that, if not avoided,
could result in death or serious injury.
This symbol indicates a hazardous situation that, if not avoided, may result in
minor or moderate injury or may result in only property damage.
6.1 Piping example ···················································· 5
6.2 Precaution for installation ······································· 7
7.1 Precaution for operating procedure ························· 10
8.1 Precaution for maintenance ·································· 10
8.2 Daily and periodic inspections ······························· 11
8.3 Troubleshooting ·················································· 12
8.4 Exploded drawing ··············································· 13
8.5 Disassembly ······················································ 14
8.6 Reassembly ······················································· 15
8.7 Parts replacement procedure ································ 16
Table of Contents
MODEL TSF-8,8F
STEAM TRAP
.
■EPDT-320b■
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Yoshitake TRAP STAR TSF-8
Summary of Contents for Yoshitake TRAP STAR TSF-8
-
Page 1: Table Of Contents
STEAM TRAP PRODUCT MANUAL Thank you very much for choosing the Yoshitake’s product. To ensure the correct and safe use of the product, please read this manual before use. This manual shall be kept with care for future references. The symbols used in this manual have the following meanings. -
Page 2: Usage Of The Product
1. Usage of the product The TSF-8 can discharge condensate effectively without retention, and realize energy saving steam system without steam loss. In addition, built in thermostatic air vent discharges air inside the piping and shortens warming-up time. So, the product is suitable for steam equipments used in various industries such as air-conditioning equipment, hot-water supply equipment, plant, and food. -
Page 3: Dimensions And Weights
3. Dimensions and Weights (mm) Weight Nominal Ｌ model size (kg) Rc1/2 TSF-8 Rc3/4 (mm) Flange JIS10K/20K FF Weight Nominal Ｌ model size (kg) 4-15 4-15 TSF-8F 4-19 ■EPDT-320b■... -
Page 4: Operation
4. Operation Air vent Float 1. Start-up of the operation At start-up, since the float is down, the valve is closed. In this state, air in the system and piping is discharged out through the air vent which is opened. When condensate flows into the product, the float lifts up and opens the valve, and then discharges condensate. -
Page 5: Maximum Continuous Discharge Capacity
5. Maximum Continuous Discharge Capacity 1. Discharging capability of the steam trap differs by working differential pressure, that is, difference between inlet pressure and outlet pressure (back pressure). In selecting discharge capacity, consider outlet pressure. If inlet pressure is 0.5 MPa and outlet pressure is 0.2 MPa, discharge capacity is of working differential pressure of 0.3 MPa. -
Page 6: Installation
6. Installation 6.1 Piping example Stop valve Pressure gauge Drip leg Pressure gauge Stop Stop Stop Check Sight valve valve valve valve TSF-8 glass Strainer Steam Trap Stop valve Description Correct Incorrect If the product is installed close Regulating Regulating valve to a regulating valve, make valve... - Page 7 Description Correct Incorrect Install the product below a device which generates condensate. Install the products for each device independently. The diameter of collecting pipe shall be more than summation of sectional areas of discharge pipes. In addition, install check valves for back flow prevention.
-
Page 8: Precaution For Installation
Description Correct Incorrect End portion of discharge pipe shall be off the water surface in the pit. * If the discharge pipe is in contact with the water, it sucks up dirty water in the pit and causes malfunction of the product. Provide a by-pass line around the product, and install stop By-pass valve... - Page 9 3. Check installation posture. * Wrong posture hampers proper operation. WRONG BOTTOM * Allowable tilt from horizontal line is within ±10°. 4. Make sure to support the piping immovably. * If an excessive piping stress is applied, the product may not open or close. 5.
- Page 10 6. Secure enough space for maintenance (such as cleaning of strainer), inspections and repair as shown below. * Failure to follow this notice prevents maintenance, inspection and repair. 175 mm or more 7. Slope the piping and place the product at as a low position as possible in order to make condensate flow into the product by its own weight.
-
Page 11: Operating Procedure
7. Operating Procedure 7.1 Precaution for operating procedure Warning 1. Before leading fluid, make sure that the product is securely connected to piping and that there is no loose. * Failure to follow this notice may result in scalds or injury due to blow-off. 2. -
Page 12: Daily And Periodic Inspections
5. To assemble, connect all the parts securely and tighten the bolts uniformly in diagonal order. * Failure to follow this notice may cause malfunction or outside leakage. 6. When repairing, do not use the parts other than the dedicated parts manufactured by Yoshitake. Do not modify the product. -
Page 13: Troubleshooting
8.3 Troubleshooting Trouble Cause Remedy Condensate is not 1. Blockage of foreign substances in 1. Disassemble and clean it. discharged. a discharge hole of the valve seat. 2. The screen is clogging. 2. Disassemble and clean it. 3. The float (P) is damaged. 3. -
Page 14: Exploded Drawing
8.4 Exploded drawing The parts shown in the rectangle boxes are available as consumable supply. The air vent(P) cannot be removed from the cover. ■EPDT-320b■... -
Page 15: Disassembly
8.5 Disassembly Tools to be used Name of tool Size (Nominal size) Ring wrench 19 mm [Procedure 1] Loosen the bolts fixing the cover with ring wrench (width across flat: 19 [Procedure 1] mm), and remove the cover and gasket from the body. Pull out the screen from the body. -
Page 16: Reassembly
8.6 Reassembly Tools to be used Name of tool Size (Nominal size) * Tightenable with torque of 45 N・m Torque Wrench Width across flat: 19 mm [Procedure 1] Connect the float holder and float (P) assembly with the spindle. Check that the float (P) assembly moves smoothly, and that the seat surface of the valve is in contact with that of the valve seat. -
Page 17: Parts Replacement Procedure
[Procedure 3] Install the cover gasket to the cover. Make the oval-shaped holes on the cover and on the cover gasket in the same position. Make sure to use a new cover gasket. Apply lubricant agent to the cover gasket (Recommendation: SOLVEST No.110 paste, STT Inc.). -
Page 18: Warranty Information
( e.g. in case of corrosion due to outdoor use). Fire, flood, earthquake, thunder and other natural disasters. Consumable parts such as O-ring, gasket, diaphragm and etc. Yoshitake is not liable for any damage or loss caused by malfunction or defect of the product. PDD-046f...
