Thank you very much for choosing the Yoshitake's product. To ensure the correct and safe use of the product,
please read this manual before use. This manual shall be kept with care for future references.
The symbols used in this manual have the following meanings.
Warning
Caution
1. Specifications ···························································· 1
2. Dimensions and Weights ············································· 2
3. Operation ································································· 2
4. Maximum Continuous Discharge Capacity ······················ 3
Warranty Information
PRODUCT MANUAL
This symbol indicates a potentially hazardous situation that, if not avoided,
could result in death or serious injury.
This symbol indicates a hazardous situation that, if not avoided, may result in
minor or moderate injury or may result in only property damage.
5.1 Piping example ·················································· 4-5
5.2 Precaution for installation ····································· 6-7
6.1 Precaution for operating procedure ·························· 7
7.1 Precaution for maintenance ································· 7-8
7.2 Daily and periodic inspections ································ 8
7.3 Troubleshooting ················································· 8-9
7.4 Exploded drawing ················································ 9
7.5 Disassembly ················································· 10-11
7.6 Reassembly ·················································· 11-14
7.7 Parts replacement procedure ································ 14
Table of Contents
MODEL TSF-12
STEAM TRAP
EPDT-307
.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Yoshitake TRAP STAR TSF-12 Series
Summary of Contents for Yoshitake TRAP STAR TSF-12 Series
-
Page 1: Table Of Contents
STEAM TRAP PRODUCT MANUAL Thank you very much for choosing the Yoshitake’s product. To ensure the correct and safe use of the product, please read this manual before use. This manual shall be kept with care for future references. The symbols used in this manual have the following meanings. -
Page 2: Specifications
1. Specifications Model TSF-12 Nominal size 40A,50A Application Steam condensate TSF-12-1 0.01-0.1 MPa (0.1 MPa) TSF-12-2 0.01-0.2 MPa (0.2 MPa) Working pressure TSF-12-5 0.01-0.5 MPa (0.5 MPa) (Maximum working TSF-12-9 0.01-0.9 MPa (0.9 MPa) differential pressure) TSF-12-12 : 0.01-1.2MPa (1.2 MPa) TSF-12-17 : 0.01-1.7MPa (1.7 MPa) Max. -
Page 3: Dimensions And Weights
2. Dimensions and Weights (mm) Weight Nominal Ｌ Model size (kg) 21.7 Rc 1 1/2 NPT 1 1/2 TSF-12 NPT 2 24.6 3. Operation At start-up, since the float④ is down, the valve⑦ is closed. In this state, air in the system and piping is discharged out through the air vent⑱... -
Page 4: Maximum Continuous Discharge Capacity
4. Maximum Continuous Discharge Capacity 1. Discharging capacity of the steam trap differs by working differential pressure, that is, difference between inlet pressure and outlet pressure (back pressure). In selecting discharge capacity, consider outlet pressure. If inlet pressure is 0.5 MPa and outlet pressure is 0.2 MPa, discharge capacity is of working differential pressure of 0.3 MPa. -
Page 5: Installation
5. Installation 5.1 Piping example Stop valve Drip Pressure Pressure gauge gauge Stop Stop Stop Sight Check valve valve valve grass valve Strainer TSF-12 Stop Steam trap valve Description Correct Incorrect If the product is installed close Regulating Regulating valve valve to a regulating valve, make sure to install the product at... - Page 6 Description Correct Incorrect Install the products for each device independently. The diameter of collecting pipe shall be more than summation of sectional areas of discharge pipes. In addition, install check valves for back flow prevention. For condensate recovery, connect the discharge pipe to the upper part of collecting pipe.
-
Page 7: Precaution For Installation
5.2 Precaution for installation Warning 1. In order to discharge condensate to the atmosphere, lead the outlet to a safe place where there is no possibility of physical damage even if condensate blows out. * There are risks of scalding or injury when the condensate blows out. Caution 1. -
Page 8: Operating Procedure
7. Slope the piping and place the product at as a low position as possible in order to make condensate flow into the product by its own weight. 8. To install the product in a main steam pipe, provide a drip leg at the inlet side of the product. 9. -
Page 9: Daily And Periodic Inspections
5. To assemble, connect all the parts securely and tighten the bolts uniformly in diagonal order. * Failure to follow this notice may cause malfunction or outside leakage. 6. When repairing, do not use the parts other than the dedicated parts manufactured by Yoshitake. Do not modify the product. -
Page 10: Exploded Drawing
Trouble Cause Remedy Continuous 1. Foreign substances stuck on 1. Disassemble and clean them. blowout. valve, valve seat or air vent (P). 2. Abrasion or scratches on the 2. Replace the parts. valve, valve seat, air vent (P) or air vent valve seat. 3. -
Page 11: Disassembly
7.5 Disassembly Tools to be used Name of tool Size (Nominal size) 13 , 32 mm Spanner，Ring wrench Socket wrench 19 , 39 mm Radio pliers [Procedure 1] Remove the hexagon bolts and nuts that fixing the body with a spanner, wrench, etc (width across flat: 32mm). -
Page 12: Reassembly
[Procedure 5] Remove the hexagon bolt on the upper side of the plate and the bolt on the inlet side of the float holder with spanner, ring wrench, etc (width across flat: 13mm). Then remove the plate. [Procedure 6] Remove the hexagon bolt on the outlet side of the float holder with spanner, ring wrench, etc (width across flat: 13mm). - Page 13 [Procedure 1] Tighten the valve seat with a torque of 230 N･m using torque wrench(width across flat: 39 mm). [Procedure 2] Assemble the air vent valve seat, air vent cover and air vent gasket, and attach them to the cover by tightening with 50 N・m torque using torque wrench (width across flat: 19 mm).
- Page 14 [Procedure 5] Temporarily tighten the hexagon bolt at the outlet side of the float holder with a spanner, ring wrench, etc (width across flat: 13 mm). Next, align the screw hole on the inlet side of the float holder and the bottom hole of the plate, and temporarily tighten the hexagon bolt with a spanner, ring wrench, etc (width across flat: 13 mm).
-
Page 15: Parts Replacement Procedure
[Procedure 6] Put a new gasket on the cover and tighten the hexagon bolts and nuts fixing the body with 200 N・m torque using torque wrench (width across flat: 32 mm). 7.7 Parts replacement procedure Disassembly Reassembly Part name (See 7.5.) (See 7.6.) Cover gasket Procedure 1...
