Yoshitake Trap Star TSF-13 Manual

Steam trap
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Thank you very much for choosing the Yoshitake's product. To ensure the correct and safe use of the product,
please read this manual before use. This manual shall be kept with care for future references.
The symbols used in this manual have the following meanings.
Warning
Caution
1. Specifications···························································· 1
2. Dimensions and Weights ············································· 2
3. Operation ································································· 3
4. Maximum Continuous Discharge Capacity ······················· 4
8. TSF-13, 13F with Steam Lock Release (SLR) ··············· 18
Warranty Information
PRODUCT MANUAL
This symbol indicates a potentially hazardous situation that, if not avoided,
could result in death or serious injury.
This symbol indicates a hazardous situation that, if not avoided, may result in
minor or moderate injury or may result in only property damage.
5.1 Piping example ················································· 5-6
5.2 Precaution for installation ···································· 7-8
6.1 Precaution for operating procedure ·························· 9
7.1 Precaution for maintenance ···································· 9
7.2 Daily and periodic inspections ······························· 10
7.3 Troubleshooting ················································· 11
7.4 Exploded drawing ·············································· 12
7.5 Disassembly ················································· 13-14
7.6 Reassembly ·················································· 15-17
7.7 Parts replacement procedure ································ 17

Table of Contents

M O D E L T S F - 13，13F
STEAM TRAP
EPDT-348a
.
■EPDT-348a■

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Trap Star TSF-13 and is the answer not in the manual?

Questions and answers

Related Manuals for Yoshitake Trap Star TSF-13

Summary of Contents for Yoshitake Trap Star TSF-13

  • Page 1: Table Of Contents

    STEAM TRAP PRODUCT MANUAL Thank you very much for choosing the Yoshitake’s product. To ensure the correct and safe use of the product, please read this manual before use. This manual shall be kept with care for future references. The symbols used in this manual have the following meanings.

  • Page 2: Specifications

    1. Specifications Model TSF-13 TSF-13F Nominal size 40A,50A Application Steam condensate Max. pressure 1.6MPa 1.0MPa 1.6MPa Maximum working TSF-13-5: 0.5 MPa TSF-13F-5: 0.5MPa TSF-13F-5: 0.5MPa differential pressure TSF-13-10:1.0 MPa TSF-13F-10: 1.0MPa TSF-13F-10: 1.0 MPa (ΔPMX) TSF-13-14:1.4 MPa TSF-13F-14: 1.4 MPa Minimum working 0.01MPa differential pressure...

  • Page 3: Dimensions And Weights

    2. Dimensions and Weights (mm) Weight Nominal Model Connection １ （kg） size 1 1/2 19.0 JIS Rc TSF-13 20.0 (mm) Weight Nominal Model Connection １ （kg） size JIS10KRF/20KRF 24.0 EN PN16/25 24.5 ASME150LB 23.0 ASME300 LB 25.7 TSF-13F JIS10KRF/20KRF 25.0 EN PN16/25 25.3 ASME150 LB...

  • Page 4: Operation

    3. Operation At start-up, since the ⑮float is down, the ⑦valve set is closed. In this state, air in the system and piping is discharged out through the ⑯air vent which is opened. When condensate flows into the product, the ⑮float lifts up and opens the ⑦valve set, and then discharges condensate.

  • Page 5: Maximum Continuous Discharge Capacity

    4. Maximum Continuous Discharge Capacity 1. Discharging capacity of the steam trap differs by working differential pressure, that is, difference between inlet pressure and outlet pressure (back pressure). In selecting discharge capacity, consider outlet pressure. If inlet pressure is 0.5 MPa and outlet pressure is 0.2 MPa, discharge capacity is of working differential pressure of 0.3 MPa.

  • Page 6: Installation

    5. Installation 5.1 Piping example *Pipe size of the outlet side of the product should be large enough so that the discharged condensate flows without any resistance. Description Correct Incorrect If the product is installed close Regulating Regulating valve to a regulating valve, make valve sure to install the product at the inlet side of the regulating...
  • Page 7 Description Correct Incorrect Install the products for each device independently. The diameter of collecting pipe shall be more than summation of sectional areas of discharge pipes. In addition, install check valves for back flow prevention. For condensate recovery, connect the discharge pipe to the upper part of collecting pipe.

  • Page 8: Precaution For Installation

    5.2 Precaution for installation Warning 1. In order to discharge condensate to the atmosphere, lead the outlet to a safe place where there is no possibility of physical damage even if condensate blows out. * There are risks of scalding or injury when the condensate blows out. Caution 1.
  • Page 9 Secure enough space for maintenance, inspections and repair as shown below. * Failure to follow this notice prevents maintenance, inspection and repair. *Common to 40A and 50A Slope the piping and place the product at as a low position as possible in order to make condensate flow into the product by its own weight.

  • Page 10: Operating Procedure

    5. To assemble, connect all the parts securely and tighten the bolts uniformly in diagonal order. * Failure to follow this notice may cause malfunction or outside leakage. 6. When repairing, do not use the parts other than the dedicated parts manufactured by Yoshitake. Do not modify the product.

  • Page 11: Daily And Periodic Inspections

    7.2 Daily and periodic inspections Conduct daily and periodic inspections in order to maintain the optimal performance of the product. See ”7.3 Troubleshooting” on Page 13 for the remedies if trouble is observed. Daily inspection (once a day) ⚫ Conduct daily inspection during operation of the product. Items Standards for Inspection Discharge condition...

  • Page 12: Troubleshooting

    7.3 Troubleshooting Trouble Cause Remedy Condensate is not 1. Blockage of foreign substances 1. Clean the ⑦valve set. discharged. in the valve seat. *See Procedure 3, “7.5 Disassembly” on Page 15. 2. ⑮Float is broken 2. Change it into new one. 3.

  • Page 13: Exploded Drawing

    7.4 Exploded drawing 40A Exploded drawing 50A Exploded drawing *The parts shown in the rectangle boxes are available as consumable supply. *The ⑯air vent cannot be removed from the ②cover. *⑦Valve Set can not be disassembled. ■EPDT-348a■...

  • Page 14: Disassembly

    7.5 Disassembly ⚫ Tools to be used Name of tool Size (Nominal size) Width across flat:10 mm* Spanner , 13 mm* , 17mm, 19mm For 40A * For 50A Remove the ⑤ nut that secures the ① body with a spanner (19 mm [Procedure 1] widthacross flats), and remove the ①body and the ③body gasket from the ②cover.
  • Page 15 Remove the ⑦valve set from the ②cover. [Procedure 4] 40A :Remove the ⑭hexagon bolt with a spanner (width across flats: 10 mm). Remove the ⑩float protector and remove the ⑦valve set from the ②cover. 50A :Remove the ⑬nut with a spanner (13 mm width across flats) and remove the ⑩float protector.

  • Page 16: Reassembly

    7.6 Reassembly ⚫ Tools to be used Name of tool Size (Nominal size) Tightenable with torque of 70N・m Torque Wrench Width across flat: 19 mm Tightenable with torque of 9 N・m, Open-head type Torque Wrench Width across flat: 10 mm Tightenable with torque of 15 N・m Torque Wrench Width across flat: 13 mm...
  • Page 17 Attach the ⑦valve set to the ②cover. [Procedure 2] 40A: Attach the ⑩float protector and tighten the ⑭hexagon bolt with a wrench (width across flats: 10 mm) to a torque of 9 Nm. Also, tighten the ⑭hexagon bolts of each part uniformly so that they are not one-sided. 50A:Attach the ⑩float protector and ⑨spacer, and tighten the ⑬nut with a torque wrench to a torque of 15 Nm.

  • Page 18: Parts Replacement Procedure

    [Procedure 3] Apply adhesive (Henkel LOCTITE 272 recommended) to the threads of the ⑮float. Then attach the ⑮float to the float arm using a spanner (width across flats 17mm). [Procedure 4] Apply paste-like lubricant (recommended: STT Inc, SOLVEST No.110) to the ③body gasket, and attach it to the ①body.

  • Page 19: Tsf-13, 13F With Steam Lock Release (Slr)

    8．TSF-13,13F with Steam Lock Release（SLR） 8.1 What is SLR If you need the product with ⑱Steam Lock Release (SLR), please let us know when you purchase. It cannot be attached to the standard product later. Steam locking occurs when the pipe to the trap is filled with steam and the steam prevents condensate from flowing into the trap.
  • Page 20 8.3 How to use SLR (１) To open the ⑯Air Vent Turn the slotted head of ⑱SLR in the direction of A by a flathead screwdriver. The more you screw in, the more the ⑯Air Vent opens. However, do not screw in beyond E ring stopper. If you turn it any further, the ⑯Air Vent may be damaged.
  • Page 21 8.5 How to replace SLR 【Procedure 1】 Remove the ⑱SLR from ②Cover with a spanner (width across flats: 23mm). 【Procedure 2】 Apply a paste-like lubricant (recommended: STT Inc, SOLVEST No. 110) to the ⑲ SLR Gasket, and attach it to the ②Cover. 【Procedure 3】...
