Unlock + Trunk Button (0.5 Sec.) – Passive Arming On/Off – Tapping the Unlock and Trunk Buttons at the
same time turns Passive mode on. Your parking lights will flash once when you tap these buttons to turn
this feature on and twice to turn this feature off. With Passive mode on, your vehicle will lock and arm 30
seconds after the door is opened and closed. The parking lights will flash and/or siren will chirp every 10
seconds up to 30.
Unlock + Key Button (0.5 Sec.) – Timer Start On/Off – By activating this feature, you turn on the time start
or hot/cold starting. Your parking lights will flash once when you tap these buttons to turn this feature on
and twice to turn this feature off. This must be set after you close the vehicle door. If you remote start or
start the vehicle with the key then it cancels this mode. Consult your installer.
Timer Start – Your installer can give you 2 choices – 1.5 or 3 hours. Example: If your installer programs 3
hours and you turn on this option with Unlock + Key Button, your car will start every 3 hours for 4 minutes
until cancelled by turning the Timer Start off.
Trunk + Key Button (0.5 Sec.) - Turbo Mode On/Off – By tapping the Trunk and Key buttons
simultaneously you activate Turbo Mode. Your parking lights will flash once when you tap these buttons to
turn this feature on and twice to turn this feature off. By activating this function you can run your vehicle
for 1, 2 or 4 minutes after you set your emergency brake. You must manually arm your CompuStar once
you shut your door. This feature and run time must be programmed by your CompuStar dealer.
Trunk + Key Button (2.5 Sec.) - Query - Holding this button down for 2.5 seconds will initiate the Query
function on your system. This is used to activate Secure Aux on your system. You cannot accidentially
activate Aux 1 or Aux 2 unless you Query your system first.
___________________________________________________________________________________________________________________
D
M
IAGNOSTIC
ESSAGES
1. Whenever the system fails to remote start, the vehicle provides you with diagnostic error messages: # of times parking lights flash. The
vehicle will first flash the parking lights 3 times followed by the remote start error.
2. When the vehicle is disarmed, siren chirp will indicate which zone has been triggered while armed:
a) Parking Light & Chirps 4 times - Optional
Number of Parking
Light Flashes
1
Motor running
2
Key in ignition on position
3
Door open (manual transmission only)
4
Trunk open
5
Foot brake on
6
Hood open
7
Reservation off (manual transmission only)
No tach signal or voltage sensing failure
8
(please see your CompuStar installer)
Sensor Triggered
c) 6 Times: Door, Hood, or Trunk was triggered
Remote Start Error
b) 5 Times – Shock Sensor triggered
4
