CompuSTAR 2W900FMR-2ND-5P User Manual

2way 900mhz remote 2way super heterodyne lcd remote us style
Hide thumbs

Advertisement

Table of Contents

By Firstech LLC Version 1.0
Toll Free : 888-820-3690
21911 68
th
Ave S
Kent, WA 98032
www.firstechllc.com
2W900FMR-2nd-5P
2WSHLCD-5P
FCC ID : O44J2W907R
FCC ID : O44JMR5100
www.compustar.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2W900FMR-2ND-5P and is the answer not in the manual?

Questions and answers

Glen Sterling
March 15, 2025

HOW DO i SET THE TIME ON MY OLD 2W8000FMR-5A

0
1 comments:
Mr. Anderson
May 14, 2025

To set the time on a CompuSTAR 2W8000FMR-5A:

1. Tap button (II) for 0.5 seconds. The Timer icon and clock will flash.
2. Tap button (I) for 0.5 seconds to adjust the hour.
3. Tap button (II) for 0.5 seconds to adjust the minute.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for CompuSTAR 2W900FMR-2ND-5P

Summary of Contents for CompuSTAR 2W900FMR-2ND-5P

  • Page 1 By Firstech LLC Version 1.0 www.firstechllc.com www.compustar.com 2W900FMR-2nd-5P 2WSHLCD-5P FCC ID : O44J2W907R FCC ID : O44JMR5100 Toll Free : 888-820-3690 21911 68 Ave S Kent, WA 98032...
  • Page 2 By Firstech, LLC By Firstech, LLC By Firstech, LLC...

  • Page 3: Warranty Coverage

    Introduction Warranty Coverage Thank you for purchasing a CompuStar system for your vehicle. In order to truly enjoy the benefits of this system, we recommend that you thoroughly review Caution: The Manufacture’s warranty will be voided if this product is installed by anyone other than an authorized CompuStar dealer. For complete the following manual.

  • Page 4: Remote Reference

    Remote Reference Remote Reference 1W900FMR 1WSHR (1-Way 900MHz) (1Way Super Heterodyne) 2W900FMR-2nd-5P (2-Way 900MHz) 2WSHLCDR (2-Way Super Heterodyne) Applicable to the following models Applicable to the following models 2W900FM 2WSHLCD -AS(DT) (alarm and remote start) -AS(DT) (alarm and remote start) Front Side Rear...

  • Page 5: Quick Reference

    Quick Reference Quick Reference When servicing or loaning your vehicle to others, the CompuStar system should be placed in Valet Mode. Valet Mode prevents the system from The only regular maintenance this system requires is remote control battery replacement. No programming is required when replacing remote starting and disables all alarm functions.
  • Page 6 Quick Reference Quick Reference STEP 1: Enter remote programming mode by holding down buttons (II + III) for 2.5 seconds. The remote will beep once and the LCD will read Button Duration Additional Programming Function / Description “Prog” to indicate that you have successfully entered programming mode. Required Locks doors and/or arms alarm.
  • Page 7 Quick Reference Quick Reference Button Duration Additional Programming Function / Description Button Duration Additional Programming Function / Description Required Required 0.5 seconds no Locks doors and/or arms alarm. 0.5 seconds Activates passive arming (vehicle will arm/lock 30 seconds after the last door is closed) 2.5 seconds Accesses remote option programming II + III...
  • Page 8 Quick Reference Remote LCD(liquid crystal display) Diagram and lcons Your remote pager will indicate the status of your vehicle while in range. The unique LCD design will visually display such icons as lock/unlock status, remote start confirmation and remaining run time, impact/shock notification, battery voltage, temperature display and much more. Button Duration Additional Programming Function / Description...
  • Page 9 Remote LCD(liquid crystal display) Diagram and lcons Remote LCD(liquid crystal display) Diagram and lcons Engine Running Lock/Arm - Unlock/Disarm This icon will be displayed while the vehicle is running after it has been remote started. This icon indicates whether the system is locked/armed or unlocked/disarmed. While armed, the system will monitor the doors, trunk, hood, shock sensor, and aux inputs.
  • Page 10 Remote LCD(liquid crystal display) Diagram and lcons Remote LCD(liquid crystal display) Diagram and lcons Siren Passive Mode This icon will be displayed if the siren is turned on. Turning the siren off only applies to the chirps when arming, disarming, or This icon will be displayed if Passive mode is currently active.

  • Page 11: General System Functions

    Remote LCD(liquid crystal display) Diagram and lcons General System Functions The remote transmitter functions have been predetermined and programmed from the factory. The four button configuration allows for many functions to be performed through a series of tapping, holding and / or multiple presses of buttons. Although CompuStar remotes have numerous button functions and capabilities, please keep in mind that the most common functions are performed in one simple step.
  • Page 12 General System Functions General System Functions Press button (II) for 2.5 seconds to remote start an automatic transmission vehicle. If you are in range and if the vehicle is ready to remote start, the Tap button (I) for 0.5 seconds to lock/arm and unlock/disarm. If your vehicle is locked, tap button (I) to unlock; if your vehicle is remote will beep once and the CompuGLO backlight will light up to indicate that the remote start command has been successfully transmitted.

  • Page 13: Activating Reservation Mode

    General System Functions General System Functions Activating Reservation Mode STEP1 : While the vehicle is running, place the transmission in neutral, set the emergency / parking brake, and remove pressure from the foot brake. STEP2 : Remove the key from the vehicle s ignition. The vehicle s engine should remain running even after the key has been removed. If the vehicle Hold button (III) for 2.5 seconds to release the trunk or hatch.
  • Page 14 General System Functions General System Functions When in range of your vehicle, the remote will display the vehicle’s temperature and vehicle battery voltage upon tapping button (IV). All CompuStar 2 Way LCD remotes have the option to be muted. To make the remote silent you must turn on vibration mode; The temperature will be displayed after tapping button (IV) for 0.5 seconds.

  • Page 15: Advanced System Functions

    Advanced System Functions Advanced System Functions The following section reviews advanced system functions. Many of these functions require multiple steps or additional programming by your local authorized CompuStar dealer to be active. This feature can not be turned on with the 2 Way remote. The built in turbo timer keeps the vehicle’s engine running for either 1, 2, or 4 minutes (programmable from dealer with Option 2-2) after the vehicle key has been removed from the ignition.
  • Page 16 Advanced System Functions Advanced System Functions The RPS is an optional feature. The car call/RPS feature uses a remote paging sensor that is designed to be mounted on the inside of the windshield. The RPS is an optional feature. Basic RPS and car call functions do not require programming, however in order for the sensor to unlock/disarm the After the RPS has been triggered, the car call icon will illuminate and the remote will ring several times if the remote is in range to receive commands.
  • Page 17 Advanced System Functions Advanced System Functions Timer start mode is used to cool or warm the vehicle without manually starting with the key or from the CompuStar remote. While The optional Secure Valet Switch prevents the alarm from being put into valet mode through cycling the ignition on/off five times. The Secure Valet engaged, timer start will activate even while the remote is out of range.
  • Page 18 Advanced System Functions Advanced System Functions To program a specified start time, used for Option 3, perform the following steps; Auto Mode is only available in certain markets and is not available in the U.S. When the system is in Auto Mode, the system will detect the remote as you walk up to your vehicle and automatically unlock/disarm.

  • Page 19: Remote Coding / Programming Routine (S)

    Remote Coding / Programming Routine (S) Remote Start Error Diagnostic If the remote start fails to start the vehicle, the parking lights will flash three times immediately. Following those three flashes the parking lights will : Every CompuStar Pro remote must be coded to the system prior to performing any operations. All remotes must be coded at the same time. IMPORTANT flash again corresponding to the error table.

  • Page 20: Alarm Diagnostic

    Alarm Diagnostic Limited Lifetime Warranty While the alarm is armed, the LED will blink slowly. While the siren is going off, the LED will indicate the specific zone that was triggered. Firstech, LLC Warrants to the original purchaser that this product shall be free of defects in material and workmanship under normal use and circumstances for the period of time that the original owner of this product owns the vehicle in which it is installed;...
  • Page 21 Limited Lifetime Warranty Notes Firstech, LLC. is not RESPONSIBLE OR LIABLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, DAMAGES FOR LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE that may or may not resulted from the operation of Compustar. NOT WITH STANDING THE ABOVE, MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CONTROL MODULE AS DESCRIBED ABOVE.
  • Page 22 Notes Notes By Firstech, LLC By Firstech, LLC...
