Applicable to the following remote(s);
P2WSSR (2 Way Spread Spectrum Remote)
P2W900FMR (2 Way 900MHz Remote)
This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions;
(1) This device may not cause harmful interference.
(2) This device may accept any interference received, including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate this device.
User Manual
By Firstech LLC, Version: 1.3
WWW.COMPUSTAR.COM
1
Advertisement
Table of Contents
Related Manuals for CompuSTAR P2W900FMR
Summary of Contents for CompuSTAR P2W900FMR
- Page 1 User Manual By Firstech LLC, Version: 1.3 Applicable to the following remote(s); P2WSSR (2 Way Spread Spectrum Remote) P2W900FMR (2 Way 900MHz Remote) This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions; (1) This device may not cause harmful interference.
-
Page 2: Table Of Contents
Introduction ............................... 3 Kit(s) Contents ............................3 Warranty Coverage ........................... 3 Remote Reference ............................ 4 Quick Reference ............................5 Valet Mode .............................. 5 Remote Maintenance – Battery Replacement ..................5 Programming the Clock (LCD Remotes Only) ..................5 2 Way Remote Button Functions ......................6 1 Way Remote Button Functions ...................... -
Page 3: Introduction
Introduction Thank you for purchasing a CompuStar Pro system for your vehicle. In order to truly enjoy the benefits of this system, we recommend that you fully review the following manual. Please note that this manual applies to the PRO 2WSSR and 2W9000FMR systems, regardless of whether you purchased the alarm only, starter only or alarm/starter combination. -
Page 4: Remote Reference
Remote Reference P2WSSR (2-Way Spread Spectrum) Applicable to the following models; - P2WSS-AS (alarm and remote start) - P2WSS-A (alarm w/out remote start) - P2WSS-S (remote start w/out alarm) P1WSSR (1-Way Spread Spectrum) Optional (not included w/unit) P2W9000R (2-Way 900MHz) Applicable to the following models;... -
Page 5: Quick Reference
Quick Reference Valet Mode When servicing or loaning your vehicle to others, the CompuStar Pro system should be in Valet mode. Valet mode prevents the system from remote starting and disables all alarm functions. IMPORTANT: While in Valet mode the CompuStar will still lock and unlock power lock systems. The system can be put into valet one of two ways;... -
Page 6: Way Remote Button Functions
2 Way Remote Button Functions Additional Button Duration Programming Function / Description Required Lock/Arm and Unlock/Disarm. seconds Option 2-11 Run time extender. Resets remote start and turbo run-time while vehicle is remote started. seconds Aux 1. Triggers the auxiliary 1 output (most commonly used for rear defrost or window roll-down). seconds Activates the remote start. -
Page 7: Way Remote Button Functions
1 Way Remote Button Functions Additional Button Duration Programming Function / Description Required 0.5 seconds Lock/Arm 3.5 seconds Panic/vehicle locater (flashes vehicles parking lights and sounds siren and horn). 0.5 seconds Unlock/Disarm Aux 1. Triggers the auxiliary 1 output (most commonly used for rear defrost or window 0.5 seconds roll-down). -
Page 8: Remote Lcd (Liquid Crystal Display) Diagram And Icons
Remote LCD (liquid crystal display) Diagram and Icons Your remote pager will indicate the status of your vehicle while in range. The unique LCD design will visually display such icons as lock/unlock status, remote start confirmation and remaining run-time, impact/shock notification, battery voltage, temperature display and much more. *The above LCD layout and icons may vary slightly from the actual layout and icons displayed on your remote pager. - Page 9 Starter Icons – Engine Running This icon will be displayed while the vehicle is running after it has been remote started. Start Availability This icon will be displayed when the vehicle is ready to be remote-started. If this icon is not displayed, you will not be able to remote-start the vehicle.
-
Page 10: General System Functions
Car Mode This will be displayed while you are in 2 Car mode. 2 Car mode allows you to control another vehicle with the same system installed in it. The remote needs to be coded to the other vehicle in 2 Car mode for this feature to work. -
Page 11: Active Lock/Arm And Unlock/Disarm
Active Lock/Arm and Unlock/Disarm Tap button (I) for 0.5 seconds to lock/arm and unlock/disarm. If your vehicle is locked, tap button (I) to unlock; if your vehicle is unlocked, tap button (I) to lock. IMPORTANT: If the alarm has been triggered (Siren is going off), you must wait until the remote pager has been paged before disarming the alarm –... -
Page 12: Trunk Release
Activating Reservation Mode STEP 1: While the vehicle is running, place the transmission in neutral, set the emergency / parking brake, and remove pressure from the foot brake. STEP 2: Remove the key from the vehicle’s ignition. The vehicle’s engine should remain running even after the key has been removed. -
Page 13: Temperature And Battery Query
Tap button (II) for 0.5 seconds to trigger auxiliary output 1. Tap button (III) for 0.5 seconds to trigger auxiliary output 2. The remote will beep once and the aux icon will illuminate indicating that the auxiliary outputs have been triggered. By default, the system is in secure auxiliary mode, which requires you to tap button (IV) for 0.5 seconds prior to triggering auxiliary 1 or 2. -
Page 14: Advanced System Functions
Adjusting the shock sensor sensitivity is done at the actual sensor, which is generally mounted somewhere under the vehicle’s dashboard. The higher the number on the dial means greater sensitivity to impact. The recommended dial setting for most vehicles is somewhere between 2 & 4. If you are testing your sensor, please note that the shock sensor does not recognize impact for 30 seconds after the system has been armed. -
Page 15: Car Call/Rps (Remote Paging Sensor)
STEP 1: Enter remote programming mode by holding down buttons (II + III) simultaneously for 2.5 seconds. The remote will beep once and the LCD will read “Pro9” to indicate that you have successfully entered programming mode. STEP 2: Scroll through the remote options by taping button (IV) for 0.5 seconds. To set the alarm clock tap button (IV) two times, or until the timer and clock icons are flashing. -
Page 16: Secure Valet Switch
STEP 4: Enter the first digit of the desired four-digit pass code by knocking on the windshield in front of the RPS the desired number of times. For example, to enter 3, knock on the sensor 3 times (each time you knock the LED will flash RED) then wait. -
Page 17: Auto Mode
Option 4: Will start at the time specified on the 2 way remote once within 24 hours every day. This option requires a cold or hot temperature setting as a safety feature. In other words, prior to starting at specified time, the system will only start if it is below the cold temperature settings or above the hot temperature settings. -
Page 18: Anti Jacking Mode
Turn Auto Mode off by holding down button (I) a fourth time for 2.5 seconds. The remote will beep twice and the Auto Mode icon will disappear. Anti Jacking Mode The CompuStar systems have a built in mode that would require you to keep your remote separate from your key chain. -
Page 19: Remote Start Error Diagnostic
remote has been learned. The P2WSSR can recognize two remotes; 2 two-way remotes or 1 two-way remote and 1 one-way remote. When using 2 two-way remotes, the second remote will need to be re- synced to the antenna prior to operation (see page 10). Remote Start Error Diagnostic If the remote start fails to start the vehicle, the parking lights will flash three times immediately. -
Page 20: Limited Lifetime Warranty
Limited Lifetime Warranty Firstech, LLC Warrants to the original purchaser that this product shall be free of defects in material and workmanship under normal use and circumstances for the period of time that the original owner of this product owns the vehicle in which it is installed; except that the remote controller unit for the period of one year from the date of installation to the original owner of this product. -
Page 21: Notes
Notes: ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________... - Page 22 ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________...
- Page 23 www.compustar.com Toll Free: 888-820-3690 21911 68 Ave S Kent, WA 98032...
