EUROPEAN USERS
400V 50Hz SUPPLY DETAILS ARE
INCLUDED WITH ELECTRICAL
CONTROL BOX. DISREGARD SUPPLY
WIRING DETAILS IN THIS MANUAL
INSTALLATION AND OPERATION MANUAL
FOUR-POST OPEN FRONT ALIGNMENT LIFTS
COMMERCIAL GRADE
14,000 LBS. CAPACITY
Models:
• HDSO-14P
• HDSO-14AX
©2023 by BendPak Inc. All rights reserved.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
PLEASE READ THE ENTIRE CONTENTS OF THIS MANUAL PRIOR TO
INSTALLATION AND OPERATION. BY PROCEEDING WITH LIFT INSTALLATION
AND OPERATION YOU AGREE THAT YOU FULLY UNDERSTAND AND
COMPREHEND THE FULL CONTENTS OF THIS MANUAL. FORWARD THIS
MANUAL TO ALL OPERATORS. FAILURE TO OPERATE THIS EQUIPMENT AS
DIRECTED MAY CAUSE INJURY OR DEATH.
IMPORTANT SAFETY INFORMATION! SAVE THESE INSTRUCTIONS!
Do not attempt to install this Lift if you have never been trained on basic
Automotive Lift installation procedures. Never attempt to Lift components
without proper Lifting tools such as forklift or cranes. Stay clear of any
moving parts that may fall and cause injury. These instructions must be
followed to ensure proper installation and operation of your Lift. Failure to
comply with these instructions can result in serious bodily harm and void
product warranty.
Revision B1 – March 2023
Part Number 5900001
1645 Lemonwood Dr.
Santa Paula, CA. 93060, USA
Toll Free 1-800-253-2363
Tel: 1-805-933-9970
Fax: 1-805-933-9160
www.bendpak.com
