Pin Location; Before You Begin - Funbikes QD03K Owner's Manual

PIN LOCATION

PIN is stamp marked on an aluminum plate that is riveted on the front frame. ( see picture 4).
PIN means the Product Identify Number which is unique for each unit.

BEFORE YOU BEGIN

Remove contents from box. Remove the foam separators that protect the components from
damage during shipping. Inspect the contents of the box for scratches in the paint, dents or
kinked cables that may occurr during shipping. Because the product was 85 percent
assembled and packed at the factory, there should not be any problems, even if the box has a
few scars or dents.
Estimated Assembly and Set-Up Time
We recommend assembly by an adult with experience in motorbike or bicycle mechanics.
Allow up to 30-40 minutes for assembly.
Required Tools
Some tools may be supplied; however, we recommend the use of mechanic's grade tools. Use
the supplied tools only as a last resort.
The list of tool required is as follows
·Open end wrench 10mm / 13mm/ 17mm / 22mm
·Allen wrench 5mm / 6mm/ 8mm
·Bicycle style tire pump with pressure gauge
Assembly illustration and instruction
ASSEMBLY REAR WHEEL 4"
