Summary of Contents for Funbikes QD03
- Page 1 MINI ATV OWNER’S MANUAL Read and understand this entire manual before using! OFF ROAD USE ONLY!!!
-
Page 2: Safety Warning
INSTRODUCTION Thank you for purchasing this mini ATV. The proper care and maintenance that your vehicle requires is outlined in this manual. Following these instruction will ensure a long trouble-free operating life of this vehicle and your satisfaction with it. The owner’s manual corresponded to the latest state of this vehicle at the time of printing. - Page 3 A parent’s decision to allow his or her child to ride this product should be based on the child’s maturity, skill and ability to follow rules. Keep this product away from small children younger than age 12 and remember that this product is intended for use only by persons who are, at a minimum, completely comfortable and competent while operating the vehicle ACCEPTABLE RIDING PRACTICES AND CONDITIONS...
- Page 4 FAILURE TO USE COMMON SENSE AND HEED THE ABOVE WARNINGS INCREASES RISK OF SERIOUS INJURY. USE WITH APPROPRIATE CAUTION AND SERIOUS ATTENTION TO SAFE OPERATION. LOCATION OF WARNING STICKER Sticker A is located on the left front fender. Sticker B is located in the front of the fuel tank cap...
- Page 5 Sticker C is located on the right front fender Sticker D is located on the rear right fender. Sticker E is located on the left side of engine...
-
Page 6: Pin Location
PIN LOCATION PIN is stamp marked on an aluminum plate that is riveted on the front frame. ( see picture 4). PIN means the Product Identify Number which is unique for each unit. Inflating the Tires NOTE:The 6” rear tires are inflated when shipped, but they invariably lose some pressure between the point of manufacturing and your purchase. -
Page 7: Safety Reminders
Tire maintenance Tire tread depth should be checked regularly.( Shallower tread means less grip of tire). You must stop to use the vehicle if the tire is pierced, disassemble the tire and check it carefully. Tire maintenance should be done by an authorized technician. Tire should be replaced immediately when it is distorted or damaged. - Page 8 ■ Rear sprocket ECOLOGIC DRIVE The noise and the pollution of every vehicle depend on how it is driven. We strongly recommend you to drive steadily, without strong acceleration and deceleration During off road use, do not damage the environment, avoid noise and everything that can disturb persons and animals.
- Page 9 1. front brake lever 2. rear brake lever 3. handlebar 4. seat 5. chain cover 6. mudguarder 7. front shocker 8. bumper 9. fuel tank 10. kill switch 11.throttle 12. front brake 13. engine 14. footrest 15. lock key 16. rear brake 17.
- Page 10 1. front brake lever 2. rear brake lever 3. handlebar 4. Battery for Electric start engine 5. chain cover 6. foot rest 7. front shocker 8. bumper 9. lock key 10.steering bar 11.seat 12. fuel tank 13. kill siwtch 14.throttle 15.
-
Page 11: Before You Begin
● BEFORE YOU BEGIN Remove contents from box. Remove the foam separators that protect the components from damage during shipping. Inspect the contents of the box for scratches in the paint, dents or kinked cables that may occurr during shipping. Because the product was 85 percent assembled and packed at the factory, there should not be any problems, even if the box has a few scars or dents. - Page 12 ASSEMBLY REAR SHOCKER A: Nut M8 1pcs B: Bolt M8×40 1pcs C: Rear shock 1. Uplift the frame to align the shock (C) mounting hole to the shackle joint hole. 2. Fix the bolt (B) through the shock mounting hole and shack joint and tighten the nut (A) securely with 10mm -13mm open end wrenc ASSEMLY FRONT WHEEL...
- Page 13 ASSEBMLY FRONT SHOCK A:Nut M8 1pcs B:Bolt M8×40 1pcs C:Front shock 1. Uplift the frame to align the shock (3) mounting hole to the shackle joint hole. 2. Fix the bolt (2) through the shock mounting hole and shack joint and tighten the nut (1) securely with 10mm and 13mm open end wrench.
- Page 14 A: Bolt M8×16 1pcs B: Number board bracket C: Steering rod plate 1. Place the bracket (B) on the steering rod plate (C) with the hole in alignment. 2. Install the bolt (A) and tighten it with 10mm open end wrench ASSEMBLY HANDLEBAR WARNING: Failing to properly adjust and tighten the bolts that affix the handlebars can cause you to lose...
- Page 15 ● TECHNICAL SPECIFICATION SHEET Engine type single cylinder, 2 stroke, forced air cooling Power output 2.0kw/7500rpm Max torque 2.3 N.m/3600rpm Displacement (ml) Fuel Petrol mixed with 4% 2-stroke engine oil Compression Ratio 7.5 : 1 Transmission automatic with centrifugal clutch Start method manual pull start Optional / battery...
- Page 16 Inflating the Tires NOTE:The 6” rear tires are inflated when shipped, but they invariably lose some pressure between the point of manufacturing and your purchase. Be sure to inflate the tires to the correct PSI before first time use. Please read the specification sheet to get the information of tire pressure. Using a bicycle-style tire pump to inflate the tire to the PSI indicated on the sidewall of the tire.
- Page 17 ● ● ● ● Checks and maintenance before and after off-road use In order to avoid problems connected to the operation of the vehicle, it is advisable to perform a number of checks and maintenance operations before and after use. Just a few minutes given to these procedures will save you time and money, and will make riding much safer.
-
Page 18: Air Filter
● AIR FILTER Air filter box A is fitted directly on the carburetor. To remove the box, undo the two screws B. The filter box contains filter element C and support D Note: If filter C is very dirty, wash it in shampoo and water and then reinsert it into its casing Clean the filter every time the vehicle is used cross country. - Page 19 ● CHECKS AFTER CLEANING After cleaning the motorcycle, it is good practice to: ·Take off the flywheel cover and remove any dirt and water. ·Apply the lubricant above articulation points A and B on the rear and front swing arm . ·Carefully clean and dry the chain-gear-position assembly and then apply grease thoroughly in order keep these parts in good condition as long as possible.
-
Page 20: Troubleshooting
● ● ● ● CAUTION Always release the remaining fuel from the carburetor after use every time following the below steps 1. use a screwdriver to screw out the drain plug at the bottom of carburetor. 2. release the remaining fuel. 3. - Page 21 ● CIRCUIT DIAGRAM for electric start model...
- Page 22 Please read the owner’s manual before riding. Never operate this vehicle if you are under age 12. Never use the vehicle on public road. OFF ROAD use only. Never ride with a passenger Always use an approved helmet and protective gear NEVER use with drugs or alcohol Cold tire pressure.
