6.2 GPU Support

The system can accommodate up to two FHFL double-width GPUs, four FHFL single-width
GPUs, or six FHHL single-width GPUs.
Quantity
Available Slots
for x16 GPU
Thermal Kit
Conditions

6.3 Cable Management Arm

The system supports a cable management arm (CMA), which keeps the rear cables organized
and clear of the rail mechanisms when the system is extended out the front of the rack for
maintenance. The kit includes six fabric Velcro cable ties.
The CMA attaches to the rack mounting rails by means of four connectors. They are labeled
on the connectors 1, 2, 3, and 4.
Figure 6-1. Cable Management Arm and Velcro Straps
GPU Support
Two to six
Available slots for FHFL double-width GPU: Slot 1, 5
Available slot for FHFL single-width GPU: Slot 1, 2, 4, 5
Available slot for FHHL single-width GPU: Slot 1, 2, 3, 4, 5, 6
When using FHFL GPUs:
GPU air shroud: one MCP-310-82621-0N
1U heatsink: two SNK-P0087P
Ambient temp support depends on the CPU TDP. Check with a
Supermicro representative.
Six Velcro Straps
