PB-1000 Pro
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sound Revolution PB-1000 Pro and is the answer not in the manual?

Questions and answers

Related Manuals for SVS Sound Revolution PB-1000 Pro

Summary of Contents for SVS Sound Revolution PB-1000 Pro

  • Page 1 PB-1000 Pro OWNER’S MANUAL...
  • Page 2 AV receiver settings and more. One of the most useful features of your PB-1000 Pro subwoofer is the Free SVS App, which can be used to fine tune performance and create custom presets from the comfort of your favorite seat and the convenience of your mobile device.
  • Page 3 fine tune your subwoofer for perfect performance from the comfort of your favorite seat. In addition to the SVS mobile app you can control the primary features of the amp using the all new Intelligent Control Interface (ICI) back-lit user interface on the amplifier plate.
  • Page 4 Unbalanced (RCA) Line Level Inputs Unbalanced (RCA) Line Level Outputs USB Type A Port - Used for Firmware updates and powering a USB device like the SVS Sound- Path Wireless Audio Adapter. - Push repeatedly or long press to increase volume, raise the low pass frequency cut-off...
  • Page 5 PB-1000 Pro CONNECTING & CONTROLLING YOUR SUBWOOFER SUBWOOFER AC Power Connection Connect the subwoofer power cord to the subwoofer amplifier and directly into an AC outlet. Convenience outlets located on the rear panel of some AV receivers or pre/pros are NOT recom- mended for your PB-1000 Pro as these outlets are not meant for high power devices.
  • Page 6 Enable and adjust the on-board low pass filter of the PB-1000 Pro for a smooth blend with the main speakers. NOTE: For additional guidance on speaker/subwoofer crossover settings, please consult our SVS Sound Experts or our Merlin subwoofer matching tool at www.svsound.com/merlin.
  • Page 7 PB-1000 Pro CONNECTING & CONTROLLING YOUR SUBWOOFER SUBWOOFER High Level (Speaker Level) Connection - Multi-Channel/Stereo Applications This connection method is for multi-channel/stereo applications where the integrated pre/pro/amplifier only has high level (i.e., speaker level) outputs. Using high quality speaker wire, connect the L/R speaker level outputs from the integrated amplifier to both the loudspeakers and the subwoofer L/R speaker level inputs on the subwoofer.
  • Page 8 PB-1000 Pro CONNECTING & CONTROLLING YOUR SUBWOOFER SUBWOOFER Connecting Multiple Subwoofers or “Going Dual” Running two or more subwoofers has many acoustic benefits such as: improved frequency response throughout the listening area, fewer peaks and nulls, increased output and decreased bass localization.
  • Page 9 OUTPUTS Going Wireless If you want to add wireless connectivity via the SVS SoundPath Wireless Adapter (sold separately), your PB-1000 Pro conveniently includes a USB input on the amplifier plate to easily power the Receiver. Set-up is simple and quick and separate instructions are included with the adapter.
  • Page 10 NOTE: Volume and low pass filter can be controlled from your mobile device via the Free SVS App, or using the buttons on the rear panel interface.

  • Page 11: Subwoofer Room Placement

    PB-1000 Pro SUBWOOFER ROOM PLACEMENT SUBWOOFER Placement of subwoofers is a process driven by competing variables that differ in every home. Décor, floor space, furniture, speaker placement, seating location, and of course, sound quality all factor into the decision of where a subwoofer should be placed. If you have flexibility, there’s an artistry to subwoofer placement that can be aided by understanding some basic acoustic principles and set-up techniques.
  • Page 12 PB-1000 Pro SUBWOOFER ROOM PLACEMENT SUBWOOFER Front Placement Front of the room placement in between or just to the side of the front channel speakers is another common choice. Front of the room placement usually results in the best blending with the main speakers and center channel and minimizes localization effects.
  • Page 13 PB-1000 Pro SUBWOOFER ROOM PLACEMENT SUBWOOFER Dual Subwoofer Placement Based on our own extensive testing, and research done by the professional audio community, we recommend the following placement options for dual subwoofers: • Opposite diagonal front/rear corners. • At the mid-points of the side walls. •...

  • Page 14: Subwoofer Control Options

    PB-1000 Pro SUBWOOFER CONTROL OPTIONS SUBWOOFER Your SVS PB-1000 Pro Subwoofer can be controlled from the new SVS Mobile App or via the rear panel for unprecedented flexibility when optimizing performance for room layout, speakers, system set-up and more. SVS Subwoofer App...

  • Page 15: Advanced Subwoofer Controls

    Allows up to three pre-saved settings for movie, music and custom. This enables easy switching to optimize your PB-1000 Pro’s output and settings based on your specific listening preferences with different kinds of content. If using the SVS App, these presets can be renamed as desired.
  • Page 16 Choose whether to have your subwoofer in Auto, On (Default), or Trigger mode. Reset Resets PB-1000 Pro Subwoofer back to original Factory Settings. About this App Provides version number and other information about the SVS App and also allows you to turn performance monitoring on/off.
  • Page 17 PB-1000 Pro ADVANCED CONTROLS FEATURE TABLE SUBWOOFER FEATURE OPTIONS & RANGES FEATURE RANGE / OPTION Volume -60dB – 0dB (1dB/step) Low Pass Filter LP Frequency: 30Hz – 200Hz (1Hz/step) LP Slope: 6dB, 12dB, 18dB, 24dB Phase 0° – 180° (1degree/step) Polarity Positive (+) / Negative (-) Parametric EQ...

  • Page 18: Safety Instructions

    PB-1000 Pro SAFETY INSTRUCTIONS SUBWOOFER • Read these instructions. • Keep these instructions. • Heed all warnings. • Follow all instructions. • Do not use this apparatus near water. • Clean only with dry cloth. • Do not block any ventilation openings. Install in accordance with the manufacturer’s instruc- tions.

  • Page 19: Fcc & Ic Compliance

    PB-1000 Pro FCC & IC COMPLIANCE SUBWOOFER FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two condi- tions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 20: Warranty And Support

    SHARE YOUR THOUGHTS Our SVS Sound Experts are standing by from Monday to Friday form 9AM-9PM ET, Saturday from 12PM-6PM, and Sunday from 12PM-4PM to assist you with subwoofer set-up and optimization, AV Receiver settings and more. They can be reached by phone, email or chat via the options below.
