idatastart CMBMXA0 Installation Manual

AKX-IDS(RS)-BZ1A-[CMBMXA0]-EN
DIRECTED SMARTSTART & ADS-HRN(RS)-SM01 (OPTIONAL)
TERMS OF USE: Automotive Data Solutions Inc. ("ADS") products are strictly intended for installation by
Certified Technicians who are employed by a registered business specialized in the installation of auto-
motive aftermarket electronics products. Prior to beginning installation of an ADS product in a vehicle,
it is the Certified Technician's responsibility to review the most current Product Guide, Install Guide
and vehicle-specific notes available in Weblink®. ADS is not responsible for any damages whatsoever,
including but not limited to any consequential damages, incidental damages, damages for loss of time,
loss of earnings, loss of profit, commercial loss, loss of economic opportunity and the like that may or
may not have resulted from the use, misuse, improper installation or operation of its products. ADS
reserves itself the right to suspend any Weblink® account without notice and decline to offer technical
support to non-Certified Technicians, non-compliant Certified Technicians or end users.
Patent No. US 8,856,780 CA 2759622
Automotive Data Solutions Inc. © 2021
INSTALL GUIDE
DOCUMENT NUMBER
77310
REVISION DATE
20211012
FIRMWARE
AKX-IDS(RS)-BZ1A-[CMBMXA0]
HARDWARE
CMBMXA0
ACCESSORIES
ADS-USB (REQUIRED)
COMPATIBLE RF-KIT (OPTIONAL)
ADS-TOOLS-MB01 (OPTIONAL)
BEFORE INSTALLATION
1- Connect module to computer
2- Login to Weblink account
3- Flash firmware to module (module is not preloaded with firmware)
4- Use accessories accordingly (accessories are sold separately)
www.idatastart.com
