idatastart HC2352AC Install Manual
  1. Manuals
  2. Brands
  3. idatastart Manuals
  4. Remote Starter
  5. HC2352AC
  6. Install manual

idatastart HC2352AC Install Manual

2017 nissan qashqai pts at
Hide thumbs Also See for HC2352AC:

Advertisement

Quick Links

Download this manual See also: Installation Manual
Enlarged version
U.S. Patent No. 8,856,780
Automotive Data Solutions Inc. © 2017
INSTALL GUIDE
2017 NISSAN QASHQAI PTS AT
DOCUMENT NUMBER
REVISION DATE
20171006
FIRMWARE
ADS-RSA-NI8-[HC2352AC]
HARDWARE
HC2352AC
ACCESSORIES
ADS-USB (OPTIONAL)
ADS-WLM-AN1/ADS-WLM-AP1 (OPTIONAL)
DRONE MOBILE DR-2000 (OPTIONAL)
COMPATIBLE RF-KIT (OPTIONAL)
NOTICE
The manufacturer will accept no responsability for any electrical damage resulting from
improper installation of this product, be that either damage to the vehicle itself or to the
installed device. This device must be installed by a certified technician. Please review the
Installation Guide carefully before beginning any work.
