5. Electrical Characteristics
5. Electrical Characteristics
5.1 Absolute Maximum Ratings
Stresses beyond the absolute maximum ratings listed in the table below may cause permanent damage to the
device. These are stress ratings only, and do not refer to the functional operation of the device that should
follow the recommended operating
1. The module worked properly after a 24-hour test in ambient temperature at 25 °C, and the IOs in three domains
(VDD3P3_RTC, VDD3P3_CPU, VDD_SDIO) output high logic level to ground. Please note that pins occupied by
flash and/or PSRAM in the VDD_SDIO power domain were excluded from the test.
2. Please see Appendix IO_MUX of
5.2 Recommended Operating Conditions
Symbol Parameter
VDD33 Power supply voltage
I
Current delivered by external power supply
V DD
T Operating temperature
5.3 DC Characteristics (3.3 V, 25 °C)
Symbol
C
Pin capacitance
IN
V
High-level input voltage
IH
V
Low-level input voltage
IL
I
High-level input current
IH
I
Low-level input current
IL
V
High-level output voltage
OH
V
Low-level output voltage
OL
High-level source current
1
(VDD = 3.3 V, V
I
OH
output drive strength set to the
maximum)
conditions.
Table 5: Absolute Maximum Ratings
ESP32 Datasheet for IO's power domain.
Table 6: Recommended Operating Conditions
Table 7: DC Characteristics (3.3 V, 25 °C)
Parameter
VDD3P3_CPU power domain
>= 2.64 V, VDD3P3_RTC power domain
OH
VDD_SDIO power domain
10
Min Typical
3.0 3.3
0.5 -
–40 -
Min
-
0.75×VDD
–0.3
-
-
0.8×VDD
-
1; 2
-
1; 2
-
1; 3
-
Max Unit
3.6 V
- A
65 °C
Typ Max Unit
2 - pF
1 1
VDD +0.3
- V
1
0.25×VDD
- V
- 50 nA
- 50 nA
1
- - V
1
0.1×VDD
- V
40 - mA
40 - mA
20 - mA
