Owner's Guide and Installation Manual
Attach sales receipt to this card and retain as your proof of purchase
DATE OF PURCHASE:
MODEL NUMBER:
To register your fixture, please visit our website www.montecarlofans.com
3JVR44XXX Series Fan
CUL Model NO. : 3JVR44XX
RETAILER NAME:
RETAILER ADDRESS:
5.75 kg
12.65 lbs
Total fan weight
Advertisement
Related Manuals for Monte Carlo Fan Company 3JVR44 Series
Summary of Contents for Monte Carlo Fan Company 3JVR44 Series
- Page 1 Owner’s Guide and Installation Manual 3JVR44XXX Series Fan CUL Model NO. : 3JVR44XX Attach sales receipt to this card and retain as your proof of purchase DATE OF PURCHASE: RETAILER NAME: RETAILER ADDRESS: MODEL NUMBER: To register your fixture, please visit our website www.montecarlofans.com 5.75 kg 12.65 lbs Total fan weight...
-
Page 2: Cautions And Warnings
Cautions and Warnings WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70), including fire-rated construction. - Page 3 Mounting bracket Before you begin installing the fan, Switch Before installing this fan make sure the Use metal outlet box suitable for fan power off at Service panel and lock outlet box is properly installed to the support and use only the screws provided service disconnecting means to prevent house structure.
- Page 4 Canopy Canopy bottom cap Slot Keeper pin Yoke cover Cross pin Downrod Place downrod over canopy, canopy Slip downrod into motor housing yoke, Install ball end of downrod into mounting aligning holes and install cross pin and bottom cap and yoke cover. Thread lead bracket opening.
- Page 5 Reverse switch Canopy bottom Partially loosen one and remove one Setting the reverse switch in the down preassembled screw from mounting position will result in downward airflow bracket. Save screw. and setting the switch in the up position Lift canopy up, aligning its keyhole slot will result in upward airflow.
- Page 6 Warning: Before proceeding, be sure to shut off electricity at main switch or circuit breaker in order to avoid electrical shock. Note: Before installing the wall transmitter, place it in OFF position. (Fig.2) Make series-wound connection for the wall controller with HOT wire from house and lead wires from fan.
-
Page 7: Troubleshooting
Troubleshooting or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, installation, please call our Customer Service Center at the number printed on your parts list insert sheet. Warning and lock the service panel to prevent the power from being switched back on accidentally. If the service panel cannot be locked to prevent the power from being switched on accidentally, securely fasten a warning sign to the service panel. - Page 8 Jan.2022...
