AMP Research BedStep 75309-01A Quick Start Manual

Secure linkage in vice and tighten bolts. Do not

Torque. Allow steel bracket to rotate freely.

Remove license plate light by rotating and pulling

out. Squeeze metal tabs holding trailer hitch plug

and remove.

TECH SUPPORT 1-888-983-2204 Monday - Friday, 7:00 AM - 5:00 PM PST

Designed and manufactured by AMP Research. Patent 6,830,257 / 6,641,158 / 6,834,875 / 6,938,909 / 6,942,233 / 7,007,961 / 7,055,839 / 7,163,221

Other US and worldwide patents pending. Three-year limited warranty. "BEDSTEP" is a trademark of AMP Research.

www.amp-research.com

APPLICATION

Toyota Tundra

Remove corner bumper cap and use flat blade

screwdriver to pry loose. Use caution when re-

moving tabs.

Cover body panels

with protective tape to

prevent damage.

15mm

Remove plastic plug holding bumper cap onto

lower portion of bumper. Remove license plate

and plug behind holding bumper cap in place.

1/3

AMP PART # 75309-01A

2014 - 2021

(Non Resin Bumpers only)

Torque wrench

Flat Screwdriver

12mm 13mm

15mm 19mm

IM75309 rev 11.11.22

T-25

Table of Contents

Need help?

Do you have a question about the BedStep 75309-01A and is the answer not in the manual?

Page 1 TECH SUPPORT 1-888-983-2204 Monday - Friday, 7:00 AM - 5:00 PM PST Designed and manufactured by AMP Research. Patent 6,830,257 / 6,641,158 / 6,834,875 / 6,938,909 / 6,942,233 / 7,007,961 / 7,055,839 / 7,163,221 Other US and worldwide patents pending. Three-year limited warranty. “BEDSTEP” is a trademark of AMP Research.
Page 2 Remove bumper cap from bumper. Use flat blade Loosen and remove three lower bolts that secure screwdriver or long pliers from underside of bumper corner bracket in place. bumper and fold or squeeze tabs inward. 12mm Lift bumper cap away and loosen and remove 2 Replace Re enforcement bracket.
Page 3 Insert PT Screws into corresponding holes and torque to 6 ft-lbs / 8 N.m. NOTE: Overtightening may damage step pad. T-25 www.amp-research.com IM75309 rev 11.11.22...
Page 4 • Registration helps us keep you up to date on product information and offers To view other Amp Research products that may be offered for your vehicle. Please visit: www.amp-research.com Rev 01.05.21...
Page 5 L I MI TE D WARRAN T Y AMP RESEARCH warrants product to be free from defects in material and workmanship, for terms specified below, provided there has been normal use and proper maintenance. All remedies under this warranty are limited to the repair or replacement of any item found by the factory to be defective within the time period specified.
