BK RESOURCES BKWS-1224-PR Assembly Instructions

BKWS-1224-PR
BKWS-1230-PR
BKWS-1236-PR
BKWS-1248-PR
BKWS-1260-PR
BKWS-1272-PR
BKWS-1284-PR
BKWS-1296-PR
B
D

PARTS INCLUDED

Item Item #
A Shelf
Left Mounting Bracket
B
Right Mounting Bracket
C
D Flat Bar
E Pot Hook
*Note: 72", 84" & 96" wide Wall Shelves have a
qty of 2 Right Mounting Brackets & Flat Bars
ASSEMBLY INSTRUCTIONS
WALL SHELVES w/ POT RACK
BKWS-1624-PR
BKWS-1630-PR
BKWS-1636-PR
BKWS-1648-PR
BKWS-1660-PR
BKWS-1672-PR
BKWS-1684-PR
BKWS-1696-PR
A
E
C
Qty
1
1
*1
*1
1 per 12" of Flat Bar
BKWSE-1224-PR
BKWSE-1624-PR
BKWSE-1230-PR BKWSE-1630-PR
BKWSE-1236-PR BKWSE-1636-PR
BKWSE-1248-PR BKWSE-1648-PR
BKWSE-1260-PR
BKWSE-1660-PR
BKWSE-1272-PR BKWSE-1672-PR
BKWSE-1284-PR BKWSE-1684-PR
BKWSE-1296-PR BKWSE-1696-PR
Please make sure wall is structurally sound before installing Wall Shelf
Tools Required: Sockets or wrenches: 3/8" or 10mm

HARDWARE INCLUDED

Qty
Item Item #
F Bolt
Long Bolt
***G
H Nut **8
I Screw **4
**Note: 72", 84" & 96" wide Wall Shelves have a qty of 6 Screws & 10 Nuts
***Note: Item G only included w/ 72", 84" & 96" wide Wall Shelves
BKWS6-1436-PR
BKWS6-1448-PR
BKWS6-1460-PR
BKWS6-1472-PR
BKWS6-1496-PR
#2 Phillips bit for installing Screws
Description
M6-1.0 x 12mm Hex Cap Screw
8
M6-1.0 x 20mm Hex Cap Screw
2
M6-1.0 Lock Nut
1/4"-14 x 1" Hex Head Sheet Metal Screw
