BK RESOURCES BKWS-1224 Assembly Instructions

BKWS-1224
BKWS-1230
BKWS-1236
BKWS-1248
BKWS-1260
BKWS-1272
BKWS-1284
BKWS-1296
A
B
PARTS INCLUDED
Item Item #
A Shelf
Left Mounting Bracket
B
Right Mounting Bracket
C
*Note: 72", 84" & 96" wide Wall Shelves have a
qty of 2 Right Mounting Brackets
1. Confirm all parts/hardware are included
2. A) Turn Shelf upside down on a clean surface to avoid scratching. Attach the Left & Right Mounting Brackets to the Shelf using the Nuts & Bolts provided.
Once all the Nuts & Bolts are properly tightened, the Wall Shelf is ready to be attached to the wall.
Note: For 72", 84" & 96" Wall Shelves, the 2nd Right Mounting Bracket will be installed after the Wall Shelf is attached to the wall and will not
attach to the Shelf.
3. Attach the Wall Shelf to the wall using the Screws provided. Note: If possible, mount Wall Shelf to wall studs.
ASSEMBLY INSTRUCTIONS
WALL SHELVES
BKWS-1624
BKWS-1630
BKWS-1636
BKWS-1648
BKWS-1660
BKWS-1672
BKWS-1684
BKWS-1696
C
Qty
1
1
*1
F
BKWSE-1224 BKWSE-1624
BKWSE-1230
BKWSE-1630
BKWSE-1236
BKWSE-1636
BKWSE-1248
BKWSE-1648
BKWSE-1260
BKWSE-1660
BKWSE-1272 BKWSE-1672
BKWSE-1284 BKWSE-1684
BKWSE-1296
BKWSE-1696
Please make sure wall is structurally sound before installing Wall Shelf
Tools Required: Sockets or wrenches: 3/8" or 10mm
#2 Phillips bit for installing Screws
HARDWARE INCLUDED
Qty
Item Item #
D Bolt 4
E Nut 4
F Screw **4
**Note: 72", 84" & 96" wide Wall Shelves have 6 Screws
D
E
BKWS6-1436
BKWS6-1448
BKWS6-1460
BKWS6-1472
BKWS6-1496
Description
M6-1.0 x 12mm Hex Cap Screw
M6-1.0 Lock Nut
1/4"-14 x 1" Hex Head Sheet Metal Screw
