1/
Packing List of NVR Kit
4-cam:
NVR*1
Mounting Base*4
5V-1A USB Charger
+Cable*1
8-cam:
NVR*1
Mounting Base*8
5V-1A USB Charger
+Cable*1
Camera*4
Mounting Screw Bag*4
12V-2A Power
Supply of NVR*1
Camera*8
Mounting Screw Bag*8
12V-2A Power
Supply of NVR*1
Quick Start Guide
Quick Start Guide*1
Pin Needle*1
Battery Pack*1
Quick Start Guide
Quick Start Guide*1
Pin Needle*1
Battery Pack *1
2
USB Mouse*1
Screwdriver*1
1 meter Network Cable*1
USB Mouse*1
Screwdriver*1
1 meter Network Cable*1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ZOSI 306 Pro
Summary of Contents for ZOSI 306 Pro
- Page 1 Packing List of NVR Kit 4-cam: Quick Start Guide USB Mouse*1 NVR*1 Camera*4 Quick Start Guide*1 Mounting Base*4 Mounting Screw Bag*4 Pin Needle*1 Screwdriver*1 5V-1A USB Charger 12V-2A Power Battery Pack*1 1 meter Network Cable*1 +Cable*1 Supply of NVR*1 8-cam: Quick Start Guide USB Mouse*1 NVR*1...
- Page 2 Specification and interface description 2.1 Camera ①Antenna ⑤Network Indicator ⑨Release Button ⑬Micro SD Card Slot ②HD Lens ⑥PIR Sensor ⑩Power Switch ⑭Retaining Screw ③Infrared LEDs ⑦White LED Spotlight ⑪Loudspeaker ⑮Reset Button ④Microphone ⑧Adjusting Screw ⑫Charge Indicator ⑯Micro USB Port Description of the Camera Network indicators: Blue light on: The camera is paired or woken up Red light fleshes slowly: Waiting for pairing with NVR Red light on: Low Battery...
-
Page 3: Connection Diagram
2.3 Connection Diagram Router Mouse USB Port Camera HDMI USB2.0 DC12V VGA/HDMI Output Power Supply Camera Installation 3.1 You can place it on any flat surface: table, chair, floor etc.. 3.2 Install with Wall Mount (as shown in the figure) Drill 5 holes according to the position of the mounting base, 3.2.1 and mount the base on the wall with the included pack of screws. - Page 4 Install and tighten the safety set screw. 3.2.3 Insert and tighten the screw on the bottom of the camera battery pack. 3.2.4 Use the included screwdriver to adjust the camera to a proper angle 3.2.5 and tighten the adjustment screw. Wall Adjusting Screw...
- Page 5 Important Notes for Reducing False Alarms 4.1 To reduce false alarms, please note: Do not install the camera towards any objects with bright lights including ● sunshine, bright lamp light, etc. Do not place the camera too close to a place where there are frequently ●...
-
Page 6: Mobile App
Personal account registration 5.1 Search “ZOSI Smart” in App Store or Android Market, or scan the QR code below to download on your mobile phone.( Please grant the App to obtain the corresponding permission for the first time use, otherwise, it will cause the device fails to add, or when the camera triggers motion detection or alarm, the mobile phone cannot receive the alarm push.) - Page 7 6.1. 2 Pair the Cameras with the NVR NOTE: The battery camera has been paired with the NVR, no code pairing is required. But if the pairing information between the camera and NVR is cleared, you need to re-pair the code, and follow the steps below: （1）...
- Page 8 NOTE: If you don’ t have an account, please register first. It is recommended to use the Zosi Smart APP account to login, avoid multiple account passwords or choose local login. (no account password required).
- Page 9 7.2 Device Management (1) Add Devices: Click "Add Devices" at the bottom right>Select device model>Enter the device name, device ID, user name, device password and the number of channels>Click “Save” to complete the addition. 7.3 Enjoy Live View and Playback 7.3.1 Click “Live”...
- Page 10 7.3.2 Click the playback button in the upper left corner to enter the playback interface to watch the video playback. Faults and Solutions （1） Device Offline Check the Internet connection of the router. Check the connection between wireless NVR and the router. （2）...
