Summary of Contents for ZOSI C182-225
- Page 1 What’s in the Box Camera Quick Start Guide Mounting Screws Mounting Templates Warning Stickers NOTE: The camera and accessories vary by different models. Introduce the Camera Built-in Speaker Microphone Lens Spotlights*2 Infrared LEDs*4 Power Port Network Port...
- Page 2 Lens Spotlights*2 Infrared LEDs*2 Speaker Power Port Network Port NOTE: The actual appearance varies by different models. Connection Diagram POE 1 POE 3 POE 5 POE 7 POE 9 POE 11 POE 13 POE 15 DC 48V POE 2 POE 4 POE 6 POE 8 POE 10...
- Page 3 Install the Camera 1. Installation precautions • Avoid directing the camera towards strong light or reflective objects, including sunlight, lights, glass, mirrors and other areas with strong refraction of light sources. • Do not install at location with objects covering or obscuring the camera.
- Page 4 DOME CAMERA： ① Hold and press on the top of the ② Drill holes according to the camera and turn it counterclockwise mounting template. Then screw to get off the mounting plate from the mounting plate to the wall at the dome camera.
- Page 5 BULLET CAMERA： ① Drill holes according to the ② Align the camera bracket with the mounting template, and insert indicated location, and screw the the anchors into the holes. camera to the wall. NOTE: Place the cable in cord slot on the camera bracket.
- Page 6 Terms of Use • Use the camera only with compatible ZOSI NVRs. • Please read this guide carefully and keep it for future reference. • Follow all instructions for safe use of the product and handle with care.
- Page 7 (2) This device must accept any interference received, including inference that. may cause undesired operation. Simplified EU Declaration of Conformity ZOSI declares that the device is in compliance with the essential requirements and other relevant provisions if Directive 2014/53/EU. Correct Disposal of this Product This marking indicates that this product cannot be disposed with other household wastes throughout the EU.
