Summary of Contents for SMART Board 800ix3
- Page 1 Help us make this document better smarttech.com/docfeedback/170911 SMART Board® 800ix3 interactive whiteboard systems CONFIGURATION AND USER’S GUIDE FOR MODELS 880ix3 AND 885ix3...
- Page 2 FCC warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instructions, may cause harmful interference to radio communications.
- Page 3 Important information Before you install and use the SMART Board® interactive whiteboard system, read and understand the safety warnings and precautions in this user’s guide and the included important information document. These safety warnings and precautions describe the safe and correct operation of the interactive whiteboard system and its accessories, helping you prevent injuries and equipment damage.
- Page 4 IMPORTANT INFORMATION When mounting the projector boom on a framed or hollow wall, attach the mounting bracket to a stud to safely support the projector’s weight. If you use only drywall anchors, the drywall can fail, resulting in possible injury and damage to the product which may not be covered by the warranty.
- Page 5 IMPORTANT INFORMATION IMPORTANT Use the SMART Board 800ix3 interactive whiteboard system installation guide (smarttech.com/kb/170885) to install the interactive whiteboard and projector. Make sure an electrical socket is near the SMART product and remains easily accessible during use. Using the SMART product near a TV or radio could cause interference to the images or sound.
-
Page 6: Environmental Requirements
IMPORTANT INFORMATION CAUTION Do not block the projector’s ventilation slots and openings. If dust or small items prevent pen tray buttons from being pressed or cause constant button contact, remove the obstructions carefully. IMPORTANT Keep the remote control in a safe place because there is no other way to access menu options. - Page 7 IMPORTANT INFORMATION Environmental Parameter requirement Dust Intended for use in office and classroom environments. Not for industrial use where heavy dust and pollutants can cause malfunctions or impaired operation. Periodic cleaning is required in areas with heavier dust. See Cleaning the projector on page 32 for information on cleaning the projector.
-
Page 9: Table Of Contents
Contents Important information Safety warnings, cautions and important information Environmental requirements Chapter 1: About the interactive whiteboard system SMART Board interactive whiteboard system features Included accessories Optional accessories Chapter 2: Installing the interactive whiteboard system Choosing a location Choosing a height Securing the interactive whiteboard system Routing the cables Installing SMART software... - Page 10 CONTENTS Appendix A: Remotely managing the system through a network interface Web page management Simple Network Management Protocol (SNMP) Appendix B: Remotely managing the system through an RS-232 serial interface Connecting a room control system to the ECP Projector programming commands Appendix C: Integrating other devices Video format Connecting peripheral sources and outputs...
-
Page 11: Chapter 1: About The Interactive Whiteboard System
Chapter 1 About the interactive whiteboard system SMART Board interactive whiteboard system features SMART Board 800 series interactive whiteboard SMART U100 or SMART U100w projector Extended Control Panel (ECP) Included accessories Remote control Pens Eraser Optional accessories VGA connection kit RCA connector pod The SMART Board interactive whiteboard system combines the following components: SMART Board 800 series interactive whiteboard Wall-mounted, short-throw SMART U100 or SMART U100w projector Accessories and optional equipment... -
Page 12: Smart Board Interactive Whiteboard System Features
CHAPTER 1 ABOUT THE INTERACTIVE WHITEBOARD SYSTEM SMART Board interactive whiteboard system features The SMART Board interactive whiteboard system uses the short-throw, high-offset SMART U100 or SMART U100w projector. When the projector displays an image from your computer on the touch- sensitive interactive whiteboard, you can do everything that you can do at your computer—open and close applications, scroll through files, conference with others, create new documents or... -
Page 13: Smart U100 Or Smart U100W Projector
CHAPTER 1 ABOUT THE INTERACTIVE WHITEBOARD SYSTEM Other features of the interactive whiteboard include: A modular pen tray that automatically detects when you pick up a pen tray pen or the eraser Pen tray buttons that activate the pens’ colors and the on-screen keyboard, right-click, Orientation and Help functions A durable hard-coated surface that is optimized... -
Page 14: Included Accessories
CHAPTER 1 ABOUT THE INTERACTIVE WHITEBOARD SYSTEM A secure mounting and installation system that includes the following: An optional projector padlock ring to prevent removal of the projector from the boom Accessory mounting hardware for solid masonry or framed wall installations kit (Part Number 1007416) Templates and instructions for positioning the system safely Extended Control Panel (ECP) -
Page 15: Optional Accessories
CHAPTER 1 ABOUT THE INTERACTIVE WHITEBOARD SYSTEM Eraser The eraser resembles a rectangular chalkboard eraser. You can use a substitute object, as long as it has a similar shape, reflects infrared light and doesn’t scratch or mark the interactive whiteboard surface. Optional accessories You can add a variety of accessories to your interactive whiteboard to best meet your specific needs. -
Page 17: Chapter 2: Installing The Interactive Whiteboard System
IMPORTANT Use the SMART Board 800ix3 interactive whiteboard system installation guide (smarttech.com/kb/170885) to install the interactive whiteboard and projector. This chapter provides additional considerations and details for installing the interactive whiteboard system. -
Page 18: Choosing A Height
CHAPTER 2 INSTALLING THE INTERACTIVE WHITEBOARD SYSTEM WARNING Refer to the interactive whiteboard system’s specifications (available at smarttech.com/support) for its weight. Check your local building codes to ensure that your wall can support this weight, and use appropriate mounting hardware for your wall type. If you are installing the interactive whiteboard system on drywall, use all the included toggle bolts. -
Page 19: Securing The Interactive Whiteboard System
CHAPTER 2 INSTALLING THE INTERACTIVE WHITEBOARD SYSTEM Securing the interactive whiteboard system This section explains how to secure the different components of the interactive whiteboard system. Locking the pen tray to the interactive whiteboard To learn how to lock the pen tray to the interactive whiteboard, see the SMART Board 800 series interactive whiteboard user’s guide (smarttech.com/kb/144817). -
Page 20: Installing Smart Software
CHAPTER 2 INSTALLING THE INTERACTIVE WHITEBOARD SYSTEM IMPORTANT Do not connect the power cable to a power outlet until you have connected all the cables to the projector and ECP. Installing SMART software To access all the features of the interactive whiteboard system, install SMART software, such as SMART Meeting Pro®...
