Sultan Sonar Manual Rev 1.0
A Higher Level of Performance
Manual
Gladiator
Doppler Microwave Series
Product Flow Detection
Circular Polarisation
For more information, please visit >
www.hawkmeasure.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Doppler Microwave Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hawk Doppler Microwave Series

  • Page 1 Sultan Sonar Manual Rev 1.0 A Higher Level of Performance Manual Gladiator Doppler Microwave Series Product Flow Detection Circular Polarisation For more information, please visit > www.hawkmeasure.com...
  • Page 2: Table Of Contents

    Mounting With Windowed Weldments Part Numbering Wiring Remote Version Integral Version Remote System Connection - HAWK Supplied Cable Remote System Connection - Customer Supplied Cable Accessories MA Series Mounting Accessories MD Series Mounting Accessories - Kit Alternate Cable Type Between...
  • Page 3: Overview

    Doppler Microwave Series Principle of Operation The HAWK Gladiator Doppler Microwave flow switch is used in process applications requiring highly reliable non-contact, non intrusive product flow detection and movement. The system operates by sending out bursts of microwave energy toward the target product being monitored. The target product will reflect some of the microwave energy back to the system where it is processed to determine if the product is flowing or moving.
  • Page 4: Dimensions

    Dimensions Gladiator Doppler Microwave Series Remote Microwave System RemoteAmplifier 111.5 mm (4.4”) 78 mm (3.1”) 192.5 mm (7.6”) 14 mm (0.6”) 192.5 mm (7.6”) 147 mm (5.8”) 174 mm (6.9”) 33.0 29.0 29.0 33.0 182.5 mm (7.2”) 147 mm (5.8”) 50 mm (2”)
  • Page 5: Ma Series Weldments And Windows (Uhmw / Ptfe)

    Dimensions Gladiator Doppler Microwave Series MA Series Weldments and Windows (UHMW / PTFE) Weldment with UHMW / PTFE Windows Weldment is welded to the vessel. Window threads into Weldment Window Weldment Size Weldment / Window Parts 3” 3” Ø 6.5mm (0.25”) 92.5...
  • Page 6: Ma Series Weldments And Windows (Ceramic)

    Dimensions Gladiator Doppler Microwave Series Ø 6.5mm (0.25”) 2 Places Ø 6.5mm (0.25”) Ø 6.5mm (0.25”) 2 Places 2 Places MA Series Weldments and Windows (Ceramic) Weldment with Ceramic Windows 15mm (0.59") 75mm (2.95") Weldment is welded to the vessel. Window is locked into Weldment with Locking Retainer.
  • Page 7: Md Series Weldments And Windows 7

    Dimensions Gladiator Doppler Microwave Series MD Series Weldments and Windows Weldment with UHMW or PTFE Windows The Weldment is welded to the vessel. The Window locks into the weldment using a locking ring. UHMW / PTFE Window Weldment Assembled Piece 22mm (0.87”)
  • Page 8: Weldments And Windows (Ceramic Tile & Firebrick Assemblies)

    Dimensions Gladiator Doppler Microwave Series Weldments and Windows (Ceramic Tile & Firebrick Assemblies) Weldment with Ceramic Windows Weldment is welded to the vessel. Window is locked into Weldment with Locking Retainer Weldment / Window Parts Part Number Size Window Weldment ...
  • Page 9: Mounting

    Mounting Gladiator Doppler Microwave Series General Guidelines 1. When looking for a mounting location it is important to locate and mount the interior of the  window/sensor face for each unit flush with the vessel Do not mount wall and where minimal build-up will occur. The...
  • Page 10: Mounting

    Mounting Gladiator Doppler Microwave Series General Guidelines Mount with minimal distance between • Sensor face and chute wall. Mount adjacent to falling product flow • For slower moving materials (such as • product on conveyor) mount at 45 degree angle to incoming material direction for...
  • Page 11: Wiring

    Remote System Connection - HAWK Supplied Cable • The black wire of HAWK supplied cable comes with one end GND and the other GND / SHLD together. • The GND / SHLD end is a larger cable which has been heat shrunk. The GND only end is the same size as the other cables.
  • Page 12: Remote System Connection - Customer Supplied Cable

    Wiring Gladiator Doppler Microwave Series STATUS microwave sender STATUS Signal Remote System Connection - Customer Supplied Cable Add wire between Remote Sensor terminal 8 and Ground screw Ground screw ground screw Gladiator Remote Amplifier Use long nose Inputs model dependent...
  • Page 13: Integral System Connection

    Wiring Gladiator Doppler Microwave Series Integral System Connection RECEIVER TERMINAL LAYOUT Use long nose RELAY COMMS DC-IN AC-IN pliers to extract CAL TEST terminals CAL TEST STATUS microwave sender Signal Signal RS 485 12-30VDC 80-260VAC nd-cable must be The AC earth / ground-cable must be...
  • Page 14: Wiring - Relay Functions

    Wiring Gladiator Doppler Microwave Series Wiring - Relay Functions Switch contact actions. Relay Action Relay - (Integral Version) Relay 1 - (Remote Version) FailSafe High FailSafe Low (default) Relay Status Smart Integral Receiver terminal numbers Remote Amplifier terminal function labels...
  • Page 15: Functionality Layout

    Signal Functionality Layout Gladiator Doppler Microwave Series Integral System (3) Sensitivity dial • In ‘Hi’ switch mode used to set unit Gain • In ‘Lo’ switch mode used to adjust unit sensitivity (4) Hi / Lo switch • Hi mode for High Sensitivity to movement •...
  • Page 16: Commissioning

    Commissioning Gladiator Doppler Microwave Series Remote System 1. Mount the units according to Mounting Guidelines To protect from surges, ensure that an external ground wire is connected between the outside ground screw on the Gladiator housing and the vessel or other ground source.
  • Page 17: Integral System

    Commissioning Gladiator Doppler Microwave Series Integral System 1. Mount the units according to Mounting Requirements If units are AC powered ensure proper grounding is connected to ground screw. 2. Power the unit 3. Select the required relay action The Relay can switch ‘ON’ (FSL) or ‘OFF’ (FSH) FSH is recommended (ordinarily on/energized, switches off/ DEN when no movement is detected.
  • Page 18: Remote Software

    Remote Software Gladiator Doppler Microwave Series Operational Diagnostics Diagnostic Description Notes Sensor value indicates the amount of detected movement Sensor ranging 0-100%. When this % exceeds the Switch On% the Value relay will trigger For the level relay to switch to state '2', the Sensor value...
  • Page 19: Remote Software

    Remote Software Gladiator Doppler Microwave Series Main Menus & Interface Note: Parameters may vary depending on older software revisions Press Sensor Value To view Operational Diagnostics Select / Edit / Save Press Default Unlock UnLock Run / Return / Escape...
  • Page 20: Quickset Menu - Parameters

    Remote Software Gladiator Doppler Microwave Series Quickset Menu - Parameters Parameter Description Options Sensitivity to movement. This is the primary setup Sensitivity parameter. The higher the value the easier it is for 0-100% the system to detect movement. For the level relay to switch to state , the Sensor...
  • Page 21: Advanced Menu - Parameters

    Remote Software Gladiator Doppler Microwave Series Advanced Menu - Parameters Parameter Description Sub Menu • Auto - Switch On% set in Quickset, • Switch On% Switch Off% automatically configured Switch Mode • Switch Off% • Manual - Manually adjust Switch On and Switch Off % •...
  • Page 22: Integral Test Switch

    Integral Test Switch Gladiator Doppler Microwave Series Integral Receiver Test Switch Functions The test terminal has two potential modes of operation for Integral units and always operates in the test input mode for Remote units. Remote units have a separate, failsafe relay contact, which is always functional.
  • Page 23: Troubleshooting

    Troubleshooting Gladiator Doppler Microwave Series Troubleshooting Unit not responding to movement Relays & LCD intermittently dimming and dropping out. • Increase Sensitivity and reduce Switch Point. The system should will detect a moving hand very easily • Check incoming voltage with a multimeter in line.
  • Page 24: Error Codes

    • Ensure any junction box / wiring extensions are as subsequently failed. per HAWK wiring guide. Make sure wiring is correct especially look to the screen (earth). • Check wiring terminals for a loose or incorrect...
  • Page 25: Safety Information

    20µW/cm2 of radiated power. harmonic and spurious generations and power output. Note: The HAWK Microwave Systems are well below The HAWK Gladiator Microwave System complies with the stringent safety standards required by both the FCC Rules Part 15 for industrial controls.
  • Page 26: Part Numbering

    Part Numbering Gladiator Doppler Microwave Series Remote Version RemoteAmplifier Gladiator Amplifier (compatible with all Gladiator products), Modbus Housing S Polycarbonate Power Supply B 12-30 VDC C 36-60VDC U 12-30VDC and 90-260VAC Output Options 2 x SPDT Relays 2 x SPDT Relays & 4-20mA output 2 x SPDT Relays &...
  • Page 27: Integral Version

    Part Numbering Gladiator Doppler Microwave Series Integral Version GDMI Gladiator Doppler Microwave Integral Power Supply B 12-30 VDC U 12-30VDC and 90-260VAC Frequency 1 10.525 GHz Transducer Facing Material Selection 0 UHMW Polyethylene 1 PTFE Teflon Transducer Housing Material 1 Aluminum / Mild Steel...
  • Page 28: Ma Series Mounting Accessories

    Part Numbering Gladiator Doppler Microwave Series MA Series Mounting Accessories MA Standard Mounting Accessories Type 3” Weldment, each 3” UHMW Window & Weldment each 4” UHMW Window & Weldment each 6” UHMW Window & Weldment each 3” PTFE Window & Weldment each 4”...
  • Page 29: Md Series Mounting Accessories - Parts

    Part Numbering Gladiator Doppler Microwave Series MD Series Mounting Accessories - Parts WIN Window only BASE Weldment Only Window Facing Material Weldment Size UHMW for MD3 (-30°C to +75°C) Matches MD3 & MD6 UHMW for MD4 (-30°C to +75°C) Matches MD4 & MD7 UHMW for MD5 (-30°C to +75°C)
  • Page 30: Specifications

    Specifications Gladiator Doppler Microwave Series Operating Voltage Maximum Operating Pressure • 2 BAR • Integral 12-30VDC / Remote 12-30VDC (residual ripple no greater than 100mV) Display (Remote version only) • Integral 80-260VAC / Remote 90-260VAC 50 / 60Hz. • 2 line x 12 character alphanumeric LCD •...
  • Page 31: A Higher Level Of Performance

    Internet access and our free operations. GosHawk diagnostic & calibration software; to dial in, calibrate, test, and check the performance of HAWK We Can Help products. This innovative system allows our Global Support Team to assist with commissioning and HAWK understands the difficulties customers face after sales service of HAWK equipment worldwide.
