Hawk Gladiator Manual
Vibration smart switch series
a level switch for liquids and solids
Hide thumbs
Also See for Gladiator:
- User manual (40 pages) ,
- Instruction manual (40 pages) ,
- Manual (32 pages)
Subscribe to Our Youtube Channel
Related Manuals for Hawk Gladiator
Summary of Contents for Hawk Gladiator
- Page 1 Sultan Sonar Manual Rev 1.0 A Higher Level of Performance Manual Gladiator Vibration Smart Switch Series > A Level Switch for Liquids and Solids For more information, please visit > www.hawkmeasure.com...
-
Page 2: Table Of Contents
Table of Contents Gladiator Vibration Smart Switch Series Contents Setup Procedure Overview Smart Probe Functionality Layout Principle of Operation Smart Probe Version Typical Uses Smart Probe Version Function Remote Functionality Layout Features Remote Version Primary Areas of Application Remote Amplifier... -
Page 3: Overview
Gladiator Vibration Smart Switch Series The Gladiator Smart Vibration Switch is a third generation, state-of-the-art level probe, designed to operate in tough industrial environments. The forks of the vibration switch are driven to vibrate like a ‘tuning fork’. When material touches the forks, their vibration is changed and output will switch in response. The output has adjustable hysteresis and delays for ‘on’... -
Page 4: Typical Applications
Typical Applications Gladiator Vibration Smart Switch Series Level switch in liquid tank High and low liquid level switch in tanks High / High Level VS1200 High Level VS1100 Foam Max. 500m (1640ft) Liquid > Low Level VS1100 < RELAY 1... -
Page 5: Liquid Probe
Typical Applications Gladiator Vibration Smart Switch Series Liquid Probe Solid Probes Windows for Window for 85mm (3.3”) 85mm (3.3”) 85mm (3.3”) Window for viewing status viewing status viewing status LEDs LEDs LEDs 2 x M20 cable glands M20 cable gland or 3/4”... -
Page 6: Mounting
Mounting Gladiator Vibration Smart Switch Series Probes can be mounted from above or from the side D. Top mounting of a vessel.. When top mounting, ensure adequate clearance is provided between forks and the wall. Avoid creating Points to consider when mounting: a confined area where material could build-up over A. -
Page 7: Mounting Examples
Mounting Examples Gladiator Vibration Smart Switch Series Mounting Probes can be mounted from above or from the side. Use a protection plate for side mounting where the probe may be subject to impact damage. Install the Probe far enough away from the vessel wall to prevent the forks from coming into contact with the wall, and prevent build-up of product between the forks and the wall over time. -
Page 8: Wiring
Wiring Gladiator Vibration Smart Switch Series Integral Probe Wiring Remove Plug-In terminal TEST block for easier wiring. TEST Signal 9 10 > < The AC earth/ground cable must be connected to the ground screw inside the housing when using AC power. -
Page 9: Remote Probe To Amplifier Wiring
Wiring Gladiator Vibration Smart Switch Series Remote Probe to Amplifier Wiring Remove Plug-In terminal block for easier wiring. GLADIATOR REMOTE PROBE TERMINAL LAYOUT remote STATUS Signal 9 10 9. 10. > < Terminals 1, 2, 3, 4, 9, 10 not used. Hole for securing of... -
Page 10: Relay Functions
Wiring Gladiator Vibration Smart Switch Series Relay Functions Relay Action Level Switch Contact Action FailSafe High FailSafe Low Relay - for Smart Probe version (default) (Set Relay Action selection switch - page 13) Relay Status Relay 1 - for Remote Version... -
Page 11: Multidrop Connections
Wiring Gladiator Vibration Smart Switch Series Multidrop Connections Multidrop GPRS Connection* HawkLink HLRUG6 GPRS modem CAL TEST CAL TEST Signal Signal RELAY 1 RELAY 2 STATUS A STATUS B LINK A B Gnd A B Gnd A B Gnd Laptop or PC Communications using >... -
Page 12: Test Terminal Function Selection (Spdt Only)
Test Externally provided test button EXTERNAL PUSH BUTTON GROUND MUST CONNECT BACK TO GLADIATOR GROUND OR DC ‘-’ TERMINALS FAILSAFE OUTPUT MODE (Test switch must be in the ‘OFF’ position - default setting) Test terminal will provide an output which is able to switch an external failsafe relay or PLC/SCADA/DCS input. -
Page 13: Setup Procedure
AC Ground - must be used for Delay Potentiometer (0-20 sec) AC powered installations (Default 0 sec. at minimum position) Removable terminal block - plug in type Sensitivity Potentiometer Signal voltage test point Default 50% = 12 o’clock - Not used in Gladiator Admittance products... -
Page 14: Smart Probe Version
• Do not proceed with this step unless the product is • Make sure that external ground wire is connected not touching the probe forks. between the outside ground screw on the Gladiator • Switch the Mounting Calibration switch to ‘CAL’ (ON) housing and the roof/wall/side of the silo/tank/ position. -
Page 15: Smart Probe Version
Setup Procedure Gladiator Vibration Smart Switch Series Smart Probe Version 6. Select the sensitivity 8. Test function (used to check for malfunction of unit There are two adjustments controlling the sensitivity from remote position, PLC, SCADA etc) of the switch point: •... -
Page 16: Remote Functionality Layout
Setup Procedure Gladiator Vibration Smart Switch Series Remote Functionality Layout Calibrate button Run button Down button Up button > Relay status LEDs 1 and 2 RELAY 1 RELAY 2 STATUS A STATUS B < Display (LCD with backlight) Status LEDs A and B... -
Page 17: Remote Version
• The display will turn on and the failsafe relay will switch. • Make sure that external ground wire is connected between the outside ground screw on the Gladiator • The display will scroll through the following housing and the roof/wall/side of the silo/tank/ messages: Hawk, Amp SerialNo, Type, vessel/chute. -
Page 18: Remote Amplifier
Software Menu Gladiator Vibration Smart Switch Series Remote Amplifier Entering Data All software adjustments are achieved via the four PUSHBUTTONS on the front panel. In Run Mode (A) Press and hold - interrupts normal operations and allows access to software menu headings. -
Page 19: Software Parameters
Software Parameters Gladiator Vibration Smart Switch Series Software Tree Software Version 7.14 Sensor Value Normal Running Display 0.0% Press to view unit operation diagnostics Press To Calibrate > UnLock On first start up there is no security code protection. <... -
Page 20: Quickset Menu
Flow Chart Gladiator Vibration Smart Switch Series Quickset Menu QuickSet *When CAL is pressed ‘ edit’ will flash on the bottom line of the display for a short time to indicate that the parameter is being opened for editing. Calibrate mount will cancel the mounting influence... -
Page 21: Advanced Menu
Flow Chart Gladiator Vibration Smart Switch Series Advanced Menu Default values/settings Advanced in bold and underlined Auto - Switch point is set in QuickSet by the ‘Switch Point’ parameter. Switch Mode ‘Switch On’ = ‘Switch Point’, ‘Switch Off’ = 3/4 ‘Switch Point’ value Auto ‘Switch On’... -
Page 22: Advanced Menu
Flow Chart Gladiator Vibration Smart Switch Series Advanced Menu From previous page Reset Log Reset probe history log (Yes / No) Log will automatically reset when Cal Mounting is used in QuickSet to cancel mounting influences and re-zero the % reading. -
Page 23: Diagnostic Displays (Remote Type Only)
The diagnostic displays appear on the top line of the LCD, after pressing the Up or Down push button when the Gladiator switch is in its normal running mode. The diagnostics provide the user with valuable performance feedback on how the instrument is performing whilst in operation. -
Page 24: Troubleshooting
A. You may choose to leave the Switch Point at the After calibrating the unit the Sensor Value (%) < default 50%. The Gladiator will switch reliably upon should read approximately 0.0% with no product contact of the material to the forks. -
Page 25: Part Numbering
Part Numbering Gladiator Vibration Smart Switch Series Integral Probe Version VS1100 Gladiator Vibration Switch - Integral Probe Power Supply 12-30 VDC 12-30VDC and 90-260VAC Output Options Switch only, 1 level relay, Modbus Housing Powder Coated Aluminium, Glass viewing window 316 Stainless Steel, Glass viewing window Process Temperature 80ºC (176 ºF) -
Page 26: Remote Version
Part Numbering Gladiator Vibration Smart Switch Series Remote Version Remote Amplifier Remote Gladiator System Amplifier Housing Standard polycarbonate electronics housing Power Supply 12-30VDC 36-60VDC 12-30VDC and 90-260VAC Output Options (inc. Modbus) Switch only, 1 level relay, 1 failsafe relay Approvals Not Required ATEX Grp II Cat 3 GD T75°C IP67 Tamb -40°C to 65°C... -
Page 27: Specifications
Specifications Gladiator Vibration Smart Switch Series Operating Voltage Probe/Amplifier Separation • 7 - 30VDC (residual ripple no greater than 100mV) • Up to 500m (1640ft) using specified extension cable • 80 - 265VAC 50/60Hz Cable type between Amplifier and Probe • 36-60VDC Power Consumption • 4 conductor shielded twisted pair instrument cable •... - Page 28 GosHawk diagnostic & calibration software; to dial in, calibrate, test, and check the performance of HAWK We Can Help products. This innovative system allows our Global Support Team to assist with commissioning and HAWK understands the difficulties customers face after sales service of HAWK equipment worldwide.
