Noah Sectional
Assembly Instructions
TOOLS REQUIRED BUT NOT INCLUDED:
N/A
WARNINGS:
Do not throw away packing materials and carton until after assembly.
Assemble all parts on a clean smooth surface
CARE INSTRUCTIONS:
Avoid direct exposure to sunlight. Do not place overheat or air conditioning vents.
Adjust levelers so that the furniture sits flat on uneven floors.
Blot spills do not rub, with a clean white cloth.
Do not use harsh chemicals.
Before cleaning any part test a small spot in a hidden
area. You may need to re-tighten all bolts after initial
use.
PARTS INCLUDED
A) Allen Bolt
[M8 x 60mm] 9x
G) Ottoman Body
x1
EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC.
© 2017 UO, Inc. All rights reserved, including all applicable copyright, design and patent rights.
Any unauthorized reproduction, adaptation, distribution or other infringement will be prosecuted.
A) Flat Washer
C) Spring Washer
[M8 x 13mm] x9
[M8x18mm] x9
H) Ottoman Cushion
x1
OR
E) Legs
D) Hex Key
x9
x1
I) Sofa Body
x1
F) Soft Pads
x9
Page 1 of 3
