Application Note
CDPX-X-E2-W-5-EX2
Manual
This Application Note describes the main features of the Festo operator
panels. The manual refers to the following model CDPX-X-E2-W-5-EX2.
This operational guidelines described below is information which re-
lates to the device, installation, transportation, storage, assembly, use
and maintenance.
CDPX-X-E2-W-5-EX2
100442

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDPX-X-E2-W-5-EX2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Festo CDPX-X-E2-W-5-EX2

  • Page 1 CDPX-X-E2-W-5-EX2 Manual CDPX-X-E2-W-5-EX2 This Application Note describes the main features of the Festo operator panels. The manual refers to the following model CDPX-X-E2-W-5-EX2. This operational guidelines described below is information which re- lates to the device, installation, transportation, storage, assembly, use and maintenance.
  • Page 2 Festo SE & Co. KG. Festo SE & Co KG reserves the right to make modifications to this document in whole or in part. All brand and product names are trademarks or registered trademarks of their respective owners.
  • Page 3: Table Of Contents

    Connections .............................. 17 Power Supply, Grounding and Shielding ....................18 Battery ..............................19 Special Instructions for Use ........................20 Getting Started ............................21 System Settings ............................22 Unpacking and Packing instructions ......................24 Application Note – CDPX-X-E2-W-5-EX2 Page 3 of 24...
  • Page 5: Components/Software Used

    Type/Name Software Version Festo Designer Studio V4.5.0.224 Table 1.1: Software used Hardware Used Type/Name Firmware Version CDXP-X-E2-W-5-EX2 Config-OS 1.3.638 Main-OS 1.3.638 Bootloader 1.0.11 EtherNet Cables NEBC-R3G8M22-K-3-N-S-R3G8 NEDU-L2R1-R3U1G12-5L1-1L2-K- R3L1G12M22 Table 1.2: Hardware used Application Note – CDPX-X-E2-W-5-EX2 Page 5 of 24...
  • Page 6: Application Note Description

    ATTENTION: indicates a failure to observe safety rules and that deficiency may cause damage. ATTENTION CAUTION: indicates a failure to observe safety rules and that deficiency may cause defects to the equipment or inconsistencies.  CAUTION Page 6 of 24 Application Note – CDPX-X-E2-W-5-EX2...
  • Page 7: Product Overview

    Product Overview 3 Product Overview Festo CDPX products are ideal for field installation in critical areas. High-resolution displays and multitouch PCAP touchscreen with a robust glass front. Power-over-Ethernet (PoE) for maximum simplicity of connection using standard shielded CAT 5 wiring. Full IP protection with the use of dedicated connectors for the maximum flexibility of installation, from mounting arm to a simple M22 hole.
  • Page 8: Standards And Approvals

    EN 61000-6-3. The products are in compliance with the Restrictions on Certain Hazardous Sub- stances (RoHS) Directive 2011/65/EU In compliance with the above regulations the products are CE marked. Page 8 of 24 Application Note – CDPX-X-E2-W-5-EX2...
  • Page 9: Product Identification

    An example of the information reported is shown below: product name CDPX-X-E2-W-EX2 part number 8155219 year/week of production xx/yy serial number AA00012P8000000561AA approvals CE / UL / C-Tick / … Application Note – CDPX-X-E2-W-5-EX2 Page 9 of 24...
  • Page 10: Technical Specifications

    ± 1 KV signal line (line to earth) 0.15 – 80 MHz, 10V EN 61000-4-6 Immunity to conducted disturbances inducted by radiofrequency field Enclosure, 50/60Hz, 30A/m EN 61000-4-8 Power frequency magnetic field immunity test Page 10 of 24 Application Note – CDPX-X-E2-W-5-EX2...
  • Page 11 The viewing angles are specified for the horizontal (L,R) and vertical (U,D) axes in reference to the vertical axis of the display. The specified viewing angles above always refer to the standard mounting orientation. Application Note – CDPX-X-E2-W-5-EX2 Page 11 of 24...
  • Page 12 Projected capacitive touch screens (PCAP) are suitable for operation with or without gloves. A large number of gloves (rubber gloves, light/heavy leather gloves, disposable latex gloves, etc.) are supported. Due to the variety of commercially available gloves, however, FESTO cannot guarantee all types Page 12 of 24 Application Note – CDPX-X-E2-W-5-EX2...
  • Page 13: Technical Data

    ARM Cortex-A9 dual core 800 MHz Operating System Linux RT Flash Ethernet port 10/100 PoE 802.3af/at USB port 1 (Host V2.0, request special connector) Battery rechargeable Real Time Clock Power supply 802.3af Current consumption Weight 0.5 Kg Application Note – CDPX-X-E2-W-5-EX2 Page 13 of 24...
  • Page 14: Dimensions

    Technical Data Dimensions MODEL CDPX-X-E2-W-EX2 105.1mm/4.13” 148.3mm/5.83” 16,5mm/0.64” 17mm/0.66” Rear view Page 14 of 24 Application Note – CDPX-X-E2-W-5-EX2...
  • Page 15: Installation Environment And Procedure

    1,5mm to 3mm • max surface roughness where the gasket is applied: O120 um Usable cable Max 3mm NEBC-R3G8M22-K-3-N-S-R3G8 (IP67) Max 10mm Standard Ethernet  CAUTION Tightening torque: 1000Ncm for nut, 130Ncm for screws Application Note – CDPX-X-E2-W-5-EX2 Page 15 of 24...
  • Page 16: Safety Instructions

    Technical Data Safety instructions Page 16 of 24 Application Note – CDPX-X-E2-W-5-EX2...
  • Page 17: Connections

    The Ethernet port has two status indicators. Please see description in figure GREEN Green OFF: Valid link has not been detected ON: No activity ON: Valid link has been detected Blinking: Activity Application Note – CDPX-X-E2-W-5-EX2 Page 17 of 24...
  • Page 18: Power Supply, Grounding And Shielding

    The earth connection can also be made using the screws located near the connector. A label helps identify the ground connection. All the electronic devices in the control system must be properly grounded. Grounding must be per- formed according to applicable regulations. Page 18 of 24 Application Note – CDPX-X-E2-W-5-EX2...
  • Page 19: Battery

    The following information is maintained by the battery: hardware real-time clock (date and time) Charge: At first installation must be charged for 48 hours. When the battery is fully charged, it ensures a period of 3 months of date and time back-up at 25°C. Battery Application Note – CDPX-X-E2-W-5-EX2 Page 19 of 24...
  • Page 20: Special Instructions For Use

    Do not use sol- vents. • This device should not be used for purposes and methods other than indicated in this docu- ment and in the documentation accompanying the product. Page 20 of 24 Application Note – CDPX-X-E2-W-5-EX2...
  • Page 21: Getting Started

    Getting Started 12 Getting Started CDPX-X-E2-W-5-EX2 HMI products delivery configuration is based on a loader. Use the services of the loader to install applications on the device such as Designer Studio runtime or browsers. Designer Studio version V4.5 or higher is required. Designer Studio is a software tool that must be properly installed on a computer running Microsoft Windows.
  • Page 22: System Settings

    Designer Studio runtime is not running or the HMI device has a software fail- ure. System Mode includes all options available in User Mode and additionally includes commands dedicated to system upgrade and recovery not available when running in User Mode. Page 22 of 24 Application Note – CDPX-X-E2-W-5-EX2...
  • Page 23 (“user”). Administrator has full access to System Settings (updates of BSP and other system components). Standard user has some limitations. Note: Additional information on System Settings are available in dedicated manual Application Note – CDPX-X-E2-W-5-EX2 Page 23 of 24...
  • Page 24: Unpacking And Packing Instructions

    Unpacking and Packing instructions 14 Unpacking and Packing instructions To repack the unit, please follow the instructions backwards Page 24 of 24 Application Note – CDPX-X-E2-W-5-EX2...
