Abilize Trident Instruction Booklet page 7

Instruction Booklet: Identification of Parts
Basket assembling and disassembling:
To assemble the basket, slide the front basket (M) over
•
the hooks on the front of the tiller and into place.
To disassemble, gently slide the front basket (M) upwards
•
and off of the hooks on the front of the tiller.
Armrest assembling and angle adjustment:
Adjust armrest to most comfortable length,
•
then lock the knob (N).
Adjust screw (O) height to preferable armrest angle.
•
N
Seat height adjustment:
Remove the seat, then screw, nut and washers from seat post.
•
• Adjust seat post to desired height, then attach tightly with screw, nut and washers.
• Assemble the seat back to its original position.
Seat height adjustable 490mm / 515mm / 540mm.
•
07
M
O
