Installing Station Modules
The Pro-C Controller is supplied with a factory-installed
base module for up to 4 stations. Additional modules may
be added in increments of 3 stations (PCM-300),
9 stations (PCM-900), or 16 stations (PCM-1600). In total,
a conventionally wired system can be expanded up to
23 stations. Additional modules are sold separately.
The Pro-C Controller is also compatible with the EZ Decoder
System (EZDS) for hybrid conventional and two-wire
operations. Add a Pro-C Decoder Module (PC-DM) to enable
control for up to 32 total stations. This system uses the same
EZ-1 Decoders used with ICC2, HCC, and HPC Controllers.
For more installation and programming details, please refer
to the PC-DM Installation Guide.
8
Installing PCM Modules
The Pro-C Controller is designed with a simple-to-use
Power Lock feature that ensures the modules are energized
and firmly secured into the controller. The Power Lock
can unlock or lock all modules at the same time by simply
pushing the Power Lock slide.
1. Slide the Power Lock into the Power Off (unlocked)
position. Insert the PCM modules into the appropriate
sequential position in the controller cabinet.
2. Once all of the modules are in place, slide the
Power Lock into the Power On (locked) position to
energize and secure the modules into the controller.
3. The Pro-C Controller will automatically recognize the
correct number of stations. It is not necessary to press
the reset button on the back of the facepack or cycle
power to the controller.
hunter.help/P2C
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the PRO-C P2C Series and is the answer not in the manual?
Questions and answers
What is the difference between programs A, B & C?
Programs A, B, and C on the Hunter PRO-C P2C Series controller are separate scheduling options that let you set different watering plans. Each program can have its own start times, run times, and watering days. This allows for flexible control, such as watering different zones or plant types on different schedules. Only one type of watering day option (specific days, interval days, or odd/even days) can be used per program.
This answer is automatically generated
After I have set up a full program for Program A, how to I run the program if I want to run all the zones on an different day or time for extra watering. Looking at the manual, it looks like it says I should hold both the right arrow button down at the same time I hold the program button down. Is that correct? If not how do I enter a command to start the program manually and have all zones run their full scheduled time and stop when all zones have completed watering ? My controller is a P2C unit. Thanks !
To manually start all zones on the Hunter PRO-C P2C Series controller:
1. Hold the PRG button for 3 seconds to activate the Test Program.
2. All stations will run for the time entered for testing or diagnostics.
This will manually run all zones one after another.
This answer is automatically generated
can I put a "0" run time to skip zones on my irrigation control box? My sod replacement is partially done and I need to water certain zones daily and don't want to waste water on zones that do not have grass.
