A
Control Dial
Run
①
Normal dial position for automatic
operation
②
Set Date/Time
Set current date and time
③
Set Program Start
Set 1 to 4 start times in each program
Times
④
Set Station Run
Set run time for each station
Times
⑤
Set Days to Water
Select individual days to water, odd,
even, or interval watering schedule
⑥
Set P/MV
Enable or disable the Pump or Master
Operation
Valve for each station
⑦
Seasonal
Apply global adjustments to station run
Adjustment
times based on seasonality (5% to 300%)
⑧
Solar Sync®
Allows user to program settings when
Sensor
using Solar Sync ET Sensor
⑨
Manual — Single
Activates one-time watering of a
Station
single station
Built on Innovation
®
Pro-C Controller Components
B
Wiring Compartment
9 V Battery
①
An alkaline battery (not included) allows
programming of the controller facepack
without AC power
②
Reset Button
Resets the controller, keeping all
programmed data intact
SmartPort® Input
③
Used to connect a SmartPort Wiring
Terminals
Harness, which enables Hunter remote
controls
④
Transformer
Internal 24 VAC transformer, prewired
with power cord and plug
⑤
Junction Box
Wiring compartment that provides an area
for connecting primary AC power to the
controller
⑥
Common Terminal
Used for field Common connections to
solenoid valves; also used to complete
sensor circuit wiring
⑦
Sensor
Used to connect Hunter Solar Sync and
Inputs (x 2)
Clik Sensors
⑧
Power Slide
Slide power lock On and Off when inserting
and removing PCM output modules
5
