Summary of Contents for Hunter XC HYBRID Series
- Page 1 UNTER ONTROLLERS ROUBLESHOOTING AND ARRANTY …. NLINE XAMPLES GO TO HTTP HUNTERINDUSTRIES UPPORT RAINING IDEOS...
- Page 2 ONTENTS W ARRANTY HECK LIST XC H YBRID ROUBLESHOOTING o XC H YBRID UICK HECK AND ESET EATURES X C ROUBLESHOOTING o X C UICK HECK AND ESET EATURES P C/PCC T ROUBLESHOOTING o PRO C/PCC Q UICK HECK AND ESET...
- Page 3 WARRANTY CHECK LIST STEP 1 1. Controller must be in the valid Warranty period 2. Not Warranty if damaged by lightning strike 3. Not Warranty if damaged by insect infestation 4. Not Warranty if door left open and rain gets into internals 5.
- Page 4 HUNTER XC HYBRID TROUBLESHOOTING GUIDE SOLUTIONS PROBLEMS CAUSES The Controller is continuously Too many start times have been Only one start time is necessary to watering programmed. activate a program There is no display Check batteries or AC power Correct and errors Display reads "off"...
- Page 5 HUNTER XC HYBRID QUICK CHECK AND RESET FEATURES Clearing the Controller's Memory/Resetting the Controller: If you feel you have misprogrammed the controller, there is a process that will reset the memory to the factory defaults and erase all programs and data that have been entered into the controller.
- Page 6 Programmable Delay Between Stations: This feature allows the user to insert a delay between stations between when one station turns off and the next one turns on. Start with the dial in the RUN position. Press and hold the button down while turning the dial to the RUN TIMES position. Release the button.
- Page 7 HUNTER X CORE TROUBLESHOOTING GUIDE SOLUTIONS PROBLEMS CAUSES The Controller is continually Too many start times have been Only one start time in necessary to watering programmed activate a program There is no display Check AC power wiring Correct any errors The display reads "NO AC"...
- Page 8 Solar Sync still sending Seasonal Solar Sync's automated Seasonal Adjust when Controller Bypass Adjustment cannot be de-activated switch is in the 'Bypass" position by the Bypass switch. The Bypass switch only controls the Rain/Freeze shut off function of the Solar Sync After removing the Solar Sync The Solar Sync sensor need to he After removing the Solar Sync...
- Page 9 HUNTER X CORE QUICK CHECK AND RESET FEATURES Clearing the Controller’s Memory/Resetting the Controller If you feel you have misprogrammed the controller, there is a process that will reset the memory to the factory defaults and erase all programs and data that have been entered into the controller.
- Page 10 Programmable Delay Between Stations This feature allows the user to insert a delay between stations between when one station turns off and the next one turns on. Start with the dial in the RUN position. Press and hold the button down while turning the dial to the RUN TIMES position. Release the button.
- Page 11 HUNTER PRO C / PCC TROUBLESHOOTING GUIDE SOLUTIONS PROBLEM CAUSES There is no display. Check AC power wiring. Correct any errors. The display reads “ERR”. Electrical noise is entering the Check the SmartPort® wiring system. harness. If the wires were extended then they will need to be replaced with shielded cable.
- Page 12 The controller does not respond Controller does not recognize Press "RESET" if it still does not to all stations. Example, the modules. recognize all modules, turn off the controller has 12 stations but the power to the controller and remove display will only go to 6 stations.
- Page 13 When a field wiring short is detected, an ERR symbol preceded by the station number will momentarily flash on the controller LCD display. After the Hunter Quick Check completes running this circuit diagnostic procedure, the controller returns to the automatic watering mode.
- Page 14 If you feel that you have misprogrammed the controller, there is a process that will reset the memory to factory defaults and erase all programs and data that have been entered into the controller. Press and hold the button. Press and release the RESET button on the back of the front panel. Wait until the display shows 12:00am.
- Page 15 HUNTER ICC TROUBLESHOOTING GUIDE PROBLEM CAUSES SOLUTIONS There is no display. Check AC power wiring. Correct any errors. The display reads “P ERR”. Electrical noise is entering the Check the SmartPort® wiring system. harness. If the wires were extended then they will need to be replaced with shielded cable.
- Page 16 The controller is only recognizing Potential user programming error. Be sure dial is in correct position. eight stations when multiple Total number of stations can be modules are installed. easily checked by placing dial in SET STATION RUN TIMES position and pressing the back arrow.
- Page 17 Instead of having to physically check each field wiring circuit for potential problems, the user can run the Hunter Quick Check™ circuit test procedure. This circuit diagnostic procedure is very beneficial because of its ability to aid in quickly identifying “shorts” commonly caused...
- Page 18 When a field wiring short is detected, an ERR symbol preceded by the station number will momentarily flash on the controller LCD display. After the Hunter Quick Check™ completes running this circuit diagnostic procedure, the controller returns to the automatic watering mode.
- Page 19 HUNTER I CORE TROUBLESHOOTING PROBLEM CAUSES SOLUTIONS No display Check AC power to controller Fix power supply 14 pin connector not fully Connect ribbon cable on back on connected face pack door Module locking bar isn’t in the Slide the module locking bar into the...
- Page 20 The controller repeats a program Too many start times (user Use only one start time per active or continuously waters even programming error). Program. when it should not be on/ controller cycles over and over Controller does not recognize Module seated incorrectly Verify that modules are seated all output module (station size show the way back in the wiring...
- Page 21 After a few seconds, the display will show a number 1. Press the button. The screen will initially show a number 20 and within one second, the Hunter Quick check will begin. The controller will begin searching all stations in an effort to detect a high current path through the station terminals.
- Page 22 I CORE DUAL TROUBLESHOOTING...
- Page 26 NODE – ADVANCED FEATURES & TROUBLESHOOTING...
- Page 29 HUNTER ACC TROUBLESHOOTING PROBLEM CAUSES SOLUTIONS No display Check AC power to controller Fix power supply Facepack is not firmly seated and Seat facepack in connector locked, and/or 9-pin connector is not fully connected. Grey ribbon cable is not Connect ribbon cable to the back of...
- Page 30 Controller does not recognize Module seated incorrectly Verify that modules are seated all output module (station size the way up in wiring compartment, shown incorrect) and module lock is ON. Module slot skipped Verify that no module slots have been skipped left to right. Station output module overload Reseat Module and observe green station light flashing when module is...
- Page 31 HUNTER SOLAR SYNC TROUBLESHOOTING PROBLEM CAUSES SOLUTIONS Controller shows ERR in display Module wires not properly Check the connection between connected to controller terminal module and controller Solar Sync Module Shows ERR Connection between module and Check connection between module...
-
Page 32: Calibration Setup
CALIBRATION/ SET UP After Solar Sync has been installed and programmed, it is recommended to allow the system to run for a few days at the initial setting. Because of the variety in site conditions (including sensor location, amount of direct sunlight available to the sensor, reflective heat from surrounding structures, etc), the initial setting may require adjustment in order to arrive at the desired performance.
