SAFETY INSTRUCTIONS
• Maximum load capacity is 200 Kg
Repair and services
1) This product provides worldwide warranty, 1 year of warranty
for a whole unit, lifetime maintenance services;
2) This equipment (excluding the battery) can be used more than
10,000 times in the case of the user uses and takes good
Maintenance according to the User Manual;
3) All equipment components are not allowed to repair by user
themselves, contact the authorized dealer for overhauling.
Distributor:
Rehab and Mobility
6-8 Imboon Street, Deception Bay QLD
Level 1, 149 Princes Highway
1300 368 085
Unanderra NSW 2526
Australia
qld@rehabandmobility.com.au
Tel: +61 2 4272 2688. Fax: +61 2 4272 2699
www.rehabandmobility.com.au
www.peak-care.com.au
Peak Powerup Toilet Lift
Peak Powerup Toilet Lift
User Manual
Peak Powerup Toilet Lift
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Peak Powerup Toilet Lift
Summary of Contents for Peak Powerup Toilet Lift
- Page 1 SAFETY INSTRUCTIONS • Maximum load capacity is 200 Kg Peak Powerup Toilet Lift Repair and services 1) This product provides worldwide warranty, 1 year of warranty for a whole unit, lifetime maintenance services; 2) This equipment (excluding the battery) can be used more than 10,000 times in the case of the user uses and takes good Maintenance according to the User Manual;...
-
Page 2: Table Of Contents
Product installation handy and use it as and when required. 2. Installation of battery Peak Powerup Toilet Lift is warrantied to be free of defects in material and workmanship for twelve months from the date of 3. Installation of handrail purchase. - Page 3 A); • Power supply E (For charging battery); • Back bracket • Backrest G (backrest function) • Arm support H • Remote control I • Qualified Certificate and User Manual Peak Powerup Toilet Lift Peak Powerup Toilet Lift...
- Page 4 6) Take out the battery after lifting the equipment seat ring, or else the battery may not be taken out normally. Proposed purchase a spare battery, the battery can be charged to another, alternately use Figure 3 Power quantity display Peak Powerup Toilet Lift Peak Powerup Toilet Lift...
-
Page 5: Installation Of Handrail
Bracket until to the connecting screw holes matched, fix them by screws. Press the backrest Figure 5 Installation of backrest support and backrest onto the backrest support tube. Peak Powerup Toilet Lift Peak Powerup Toilet Lift... -
Page 6: Installation Of The Arm Support
Figure 8 Confirm the height of seat ring Rotate support feet (Figure 8) to change the height of the equipment adjusting the crossbeam at the back of the Peak Powerup Toilet Lift Peak Powerup Toilet Lift... -
Page 7: Fixing With The Toilet
4) for those poor body balance users, the crossbeam of the equipment main part A must be fixed with the toilet by bolts (as shown in Figure 9, Figure 10). Fixing mode 1: (directly fixed by bolts) Peak Powerup Toilet Lift Peak Powerup Toilet Lift... -
Page 8: Using Method Of Charger
(as shown in Figure 13). The charger indicator turns red during charging, it turns green means full battery. Figure 11 Use of power switch Figure 13 Cell charging diagram Peak Powerup Toilet Lift Peak Powerup Toilet Lift... -
Page 9: Product Dimension
3. Height: 790mm Working voltage: 24V 4. Distance of the handrail: 456mm Product rated power: 130w 5. Distance of the machine base: 425mm Water-proof grade: IP44 6. Minimum height of seat: 386mm Peak Powerup Toilet Lift Peak Powerup Toilet Lift... -
Page 10: Equipment Cleaning
2) The equipment is not water-proof, do not clean it by manual cleaning device, do not spray the equipment or immerse it in water. Peak Powerup Toilet Lift Peak Powerup Toilet Lift...
