Peak Ellipse Lite User Manual
Aluminium outdoor rollator with disc brake and suspension
Hide thumbs
Also See for Ellipse Lite:
- User manual (8 pages) ,
- User manual (8 pages) ,
- User manual (12 pages)
Subscribe to Our Youtube Channel
Related Manuals for Peak Ellipse Lite
Summary of Contents for Peak Ellipse Lite
- Page 1 User Manual Ellipse Lite Aluminum Outdoor Rollator With Disc Brake and Suspension Ellipse Lite Outdoor Ver.1.0 I Nov. 2017...
- Page 2 Thank you for purchasing the Peak-Care Ellipse Lite Outdoor Rollator. The Walking aid is suitable for a single user with limited mobility. The Ellipse Lite Outdoor Rollator is ideal for outdoor use. Kindly take time to go through this manual which gives you more details about your Ellipse Lite Outdoor Rollator.
-
Page 3: Parts List
11. Rear wheel 6. Back Rest 12. Safety bow INTRODUCTION The Walking aid is suitable for a single user with limited mobility. The Ellipse Lite Outdoor is ideal for outdoor use. ELLIPSE LITE OUTDOOR PACK INCLUDES 1 Ellipse Lite 2 Bag... -
Page 4: Height Adjustment
ATTACHING THE CARRY BAG Fold Ellipse Lite Outdoor, Remove the stopper from the tube on either side of the seat, push the sliding block from bag into the guiding sleeve and put the stopper back in place. - Page 5 Parking brake: using the finger to hold the small switch and pull the lever; it can be parked at the third position. Free parking brake: holding the brake lever and the small switch will release automatically; in the meantime, to release the parking brake for using rollator freely. Ellipse Lite Outdoor Ver.1.0 I Nov. 2017...
-
Page 6: Adjustment Of Brakes
To fold, pull seat upwards by the handle of the seat plate Once the Ellipse Lite Outdoor is folded, use the red safety clip to secure the seat. This will stop the walker from opening whilst lifting in or out of a vehicle. See below:... -
Page 7: Cleaning And Maintenance
Use only on even and solid surfaces Maximum user weight: 136 Kg Regularly check the screws and fasteners on the Ellipse Lite Outdoor and retighten if necessary. Use bag only for transport of objects and do not overload. Maximum load: 5 Kg ... - Page 8 Page intentionally left blank Ellipse Lite Outdoor Ver.1.0 I Nov. 2017...
- Page 9 Page intentionally left blank Ellipse Lite Outdoor Ver.1.0 I Nov. 2017...
