- Page 1 User Manual Ellipse Super Lite Rollator Carbon Fibre Rollator Ellipse Super Lite Ver. 3.0 I June 2017...
- Page 2 Lite is ideal for indoor and outdoor use. Kindly take time to go through this manual which gives you more details about your Ellipse Super Lite Rollator. Kindly keep this booklet handy and use it as and when required. Ellipse Super Lite is warrantied to be free of defects in material and workmanship for twelve months from the date of purchase.
- Page 3 10. Brake adjust screw 5. Interlock button for handgrips 11. Rear wheel 6. Back Rest 12. Safety bow This pack includes 1 Ellipse Super Lite 2 Bag 3 Back Rest 4 User Manual Rollator Ellipse Super Lite Ver. 3.0 I June 2017...
- Page 4 ATTACHING THE CARRY BAG Fold Ellipse Super Lite, Remove the stopper from the tube on either side of the seat, push the sliding block from bag into the guiding sleeve and put the stopper back in place BRAKING / LOCKING Pull both brake levers upwards to apply the brakes while the Ellipse Super Lite is moving.
- Page 5 To fold, pull seat upwards by the handle of the seat plate Once the Ellipse Super Lite is folded, use the red safety clip to secure the seat. This will stop the walker from opening whilst lifting in or out of a vehicle. See below:...
- Page 6 Use only on even and solid surfaces Maximum user weight: 120 Kg Regularly check the screws and fasteners on the Ellipse Super Lite and retighten if necessary. Use bag only for transport of objects and do not overload. Maximum load: 5 Kg ...
- Page 7 Page intentionally left blank - Ellipse Super Lite Ver. 3.0 I June 2017...
- Page 8 Page intentionally left blank - Ellipse Super Lite Ver. 3.0 I June 2017...
