Peak 9346376080095 User Manual

Thank You!

ADJUSTING HANDLE BAR

Take the C-cap out, draw the handle tube up
and down to the desired height.
As Figure 4 insert the C-cap though the hole.

USING BRAKES

1. Grasp both handles and brake bar, hold up the brake bar. As figure 5, fasten the
brake bar, as figure 6 when you hear "click" to make sure the brake is locked.
2. Remove the brake; rotate the red lever on the opposite side. When you hear "Clip",
the brake is removed

USING TRAY

1. Ensure the tray well installed with the rollator before using. If not installed, follow
the steps to re-fit it.
2. Support prominent position when you take off the it, hold upwards the tray, as
figure 6

CARE AND MAINTENANCE

1. Ensure that ALL attaching hardware is secured at ALL times.
2. Check screw to secure folding lever is locked. If not. Tighten if necessary.
3. Check the clip is fully snapped in the regulating hole.
4. Replace any broken, damaged or worn items immediately.

CARE OF WHEELED ACCESSORIES

1. Clean wheels with warm water and mild cleanser. Dry with clean rag.
2. Lubricate with 3-in-l oil periodically or if wheels begin to squeak
Peak Care Equipment
149 Princes Highway
Unanderra NSW 2526
Tel: +612 4272 2688
www.peak-care.com.au
Distributor:
4
Ellipse indoor Walker
Product Codes: 9346376080095, 9346376080088
User Manual
NOTE: Check all parts for shipping damage. In case of shipping damage,
Do NOT use. Contact Dealer/Carrier for further instruction.
