- Page 1 K&F SPECTRA 212 Rigging Aid Set Version V1.1 User's Manual Released: 15.10.2018 Translation of the original instructions Important Information, Please Read Before Use! KLING & FREITAG GmbH Junkersstraße 14 D-30179 Hannover TEL +49 (0) 511 96 99 70 FAX +49 (0) 511 67 37 94...
- Page 3 K&F SPECTRA 212 Rigging Aid Set Table of contents Components Required Tools Installation Steps 1 – 4 Steps 5 – 6 Using the K&F SPECTRA 212 Rigging Aid Set KLING & FREITAG GMBH © 2018 Version V1.1 Page 3 of 7...
- Page 4 User's Manual K&F SPECTRA 212 Rigging Aid Set Components Item Count Name Illustration Washer, 8.4 × 24 mm, black Allen screw, M6 × 20, with hexagon socket Compression spring M6 nut, self-locking Allen screw, M8 × 35, with hexagon socket...
- Page 5 User's Manual K&F SPECTRA 212 Rigging Aid Set Installation Repeat the following steps for each hinge leaf on the K&F SPECTRA 212 transport lid! Steps 1 – 4 Required items: Item Count Name Tool Allen screw, M6 × 20, with hexagon...
- Page 6 User's Manual K&F SPECTRA 212 Rigging Aid Set Steps 5 – 6 Required items: Item Count Name Tool Washer, 8.4 × 24 mm, black – Allen screw, M8 × 35, with hexagon Hex wrench, size 5 socket Hinge leaf, with pin –...
- Page 7 K&F SPECTRA 212 Rigging Aid Set Using the K&F SPECTRA 212 Rigging Aid Set The hinge leaves of the K&F SPECTRA 212 rigging aid set are easily accessible even with the transport lid mounted. To unscrew the hinge leaves of the K&F SPECTRA 212 rigging aid set,...
